Murata Power Solutions Pulse Transformer Through Hole Mount, 1:1:1 Turns Ratio, 67μH Primary Inductance, 0.18Ω 78602/4C

Murata Power Solutions 78602/4C is a precision pulse transformer designed for through hole mounting with a standard turns ratio of 1:1:1. It offers a primary inductance of 67μH and primary DC resistance of 0.18Ω, making it suitable for efficient coupling and signal isolation in industrial and electronic circuits.

This pulse transformer features 6 pins and compact dimensions measuring 9.52mm in length, 9mm in width, and 6.35mm in depth. Its leakage inductance is low at 0.11μH, enhancing performance in filtering and noise reduction applications.

The component is rated for a maximum operating temperature of 70°C and a minimum of 0°C, supporting use in various commercial and industrial environments including switch mode power supplies and thyristor/triac firing circuits. The 1kV isolation voltage ensures safe operation under high voltage conditions.

Additionally, the 786 series allows modification of turns ratios by connecting windings in series and can serve as a common mode choke for filtering. The unit is RoHS compliant, reflecting adherence to environmental standards.

Primary inductance is 67 microhenries ensuring stable magnetic properties. Primary DC resistance measured at 0.18 ohms for low power loss. Compact dimensions with length 9.52mm, width 9mm, and depth 6.35mm for space-efficient PCB integration.

Leakage inductance rated at 0.11 microhenries to minimize energy loss. Designed for operation over a temperature range of 0°C to 70°C for diverse environments. 6-pin through hole termination type facilitating easy assembly on PCBs.

Isolation voltage of 1kV providing reliable electrical isolation and safety. RoHS compliant product ensuring environmentally responsible design. Versatile use in coupling, thyristor/triac firing, and small-sized switch mode power supplies.

Can be connected in series to modify turns ratio or used as common mode choke in filtering applications.

This Pulse Transformer is ideal for industrial, laboratory, manufacturing, and commercial electronics applications requiring precise signal transformation and isolation. Discover more transformers and electronic components at EnvMart.
