Panasonic Shielded Wirewound Surface Mount Inductor Metal Composite Core 3.3μH ±20% 14.7A Idc ETQP5M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 5mm |
| Length | 10.7mm |
| Model | ETQP5M |
| Depth | 10mm |
| Packaging | Tape & Reel |
| Series | ETQP5M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 3.3μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 14.7A |
| Pin Count | 2 |
| Maximum DC Resistance | 7.81mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a metal composite core for high heat and vibration resistance.
- Suitable for operation up to 150°C, supporting high bias currents.
- Shielded design reduces electromagnetic interference and audible noise.
- Complies with RoHS standards and AEC-Q200 automotive quality requirements.
- Surface mount package supplied on tape and reel for assembly efficiency.
- Has a maximum DC resistance of 7.81mΩ ensuring low power losses.
- Compact dimensions of 10.7mm length, 5mm height, and 10mm depth.
- Ideal for noise filtering in various high temperature and peak current circuits.
Product Description
Panasonic ETQP5M is a high reliability shielded wirewound surface mount inductor featuring a metal composite core delivering 3.3μH inductance with a tolerance of ±20%. It supports maximum DC currents up to 14.7A and operates in temperatures ranging from -40°C to 150°C, making it suitable for demanding electronic applications requiring heat resistance and stability.
The inductor’s shielded construction minimizes electromagnetic interference and audible noise, ensuring high-quality performance in sensitive circuits. The metal composite core combined with a ferrous alloy magnetic material provides excellent inductance stability and vibration resistance due to its newly developed integral construction and molded design.
This device is compliant with RoHS standards and meets automotive standard AEC-Q200, making it fit for automotive and industrial applications. The surface mount termination style and tape & reel packaging simplify automated PCB assembly and improve production efficiency.
Key applications include noise filters for drive circuitry that require stable performance under high temperature and high peak current loads. With a low maximum DC resistance of 7.81mΩ, it offers efficient power handling capacity.
Dimensions measure 10.7mm in length, 5mm height, and 10mm depth with 2 pins, enabling compact and effective integration on densely populated circuit boards. Constructed with metal composite core for durability. Shielded to reduce interference and noise.
Capable of high current operation with low resistance. Meets automotive and RoHS quality standards. Supplied on tape and reel for assembly.
Explore Panasonic inductors in the Surface Mount Inductors category on EnvMart for reliable, high performance electronic components suited for automotive, industrial, and commercial electronics.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ETQP5M inductor has an inductance value of 3.3μH with a tolerance of ±20%.
This model supports a maximum DC current of 14.7A.
The inductor has dimensions of 10.7mm in length, 5mm in height, and 10mm in depth.
It can operate at temperatures up to 150°C.
Yes, it complies with RoHS standards and meets the automotive standard AEC-Q200.
The ETQP5M features a metal composite core, which provides high heat and vibration resistance.
This inductor is supplied on tape and reel, which facilitates automated PCB assembly.
The maximum DC resistance is 7.81mΩ, ensuring low power losses during operation.
It utilizes a surface mount termination style.
It is ideal for noise filtering in various high temperature and peak current circuits.
The maximum self-resonant frequency for this inductor is 100kHz.
This model has 2 pins for connection.
