Molex Shunt Straight Female Black Open Top 2 Way 1 Row 2.54 mm Pitch 90059-0007

Molex 90059-0007 is a C-Grid III series shunt connector featuring a straight female black open top design with 2 contacts arranged in a single row and a 2.54 mm pitch. It is engineered to deliver efficient and reliable electrical connections in compact electronic assemblies.

This shunt uses a robust polyester housing rated UL94V-0 for flame resistance and environmental durability, complemented by phosphor bronze contacts with tin plating over nickel to enhance conductivity and resist corrosion. Its compact size of 5.1 mm length, 2.54 mm width, and 4.85 mm depth accommodates low-profile electronic assemblies.

Designed for surface mount technology, this connector supports automated manufacturing processes, improving assembly line throughput. It sustains safe operation up to 1.5 amps current and 60 volts, suitable for various low-power applications. The product performs reliably within a wide temperature range from -55°C to +125°C, making it ideal for harsh operating conditions.

Compliance with UL E29179 and CSA LR19980 certifications ensures quality and safety in demanding industrial environments. The 2 contact design interfaces effectively with 0.64 mm square and round pins, making it suitable for electronic and automation systems requiring compact, stable jumper solutions.

This shunt is widely used in industrial automation, electrical devices, control systems, and instrumentation where precise and durable electrical connection is essential. Its black housing enhances compatibility across various PCB designs and electronic components.

Compact shunt connector with 2 contacts and a 2.54 mm pitch for efficient circuit bridging. Polyester housing material offers flame resistance and durability in industrial settings. Phosphor bronze contact material with tin over nickel plating provides excellent conductivity and corrosion resistance.

Surface mount termination suitable for automated manufacturing and assembly. Maximum current rating per contact of 1.5 amps and voltage rating of 60 volts. Operating temperature range from -55°C to +125°C for versatile application environments.

Complies with UL E29179 and CSA LR19980 standards ensuring safety and reliability. Dimensions optimized for compact electronic assemblies: 5.1 mm long, 2.54 mm wide, 4.85 mm depth. Compatible with 0.64 mm square and round pins, suitable for automation and electronic devices.
