Renesas Electronics Line Transceiver, 3 State, Non-Inverting, 16-Pin SOIC, CMOS/TTL Logic ICL3232ECBZ
Specifications
| Country of Origin | China |
|---|---|
| Brand | Renesas Electronics |
| Height | 2mm |
| Length | 6.5mm |
| Model | ICL3232ECBZ |
| Width | 10.65mm |
| Mount Type | Surface |
| Output type | 3 State |
| Series | ISL32 |
| Input Type | Single Ended |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Polarity | Non-Inverting |
| IC Type | Line Transceiver IC |
| Pin Count | 16 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | CMOS/TTL |
| Logic Function | CMOS, TTL |
| Minimum Supply Voltage | 3.5V |
| Maximum Propagation Delay Time @ CL | 0.15μs |
| Supply Current | 3mA |
Key Features
- CMOS/TTL logic family providing robust interface IC functionality.
- Operates with supply voltage range from 3.5V to 5.5V ensuring compatibility in diverse systems.
- Low propagation delay time of 0.15 microseconds for high-speed data transmission.
- Wide operating temperature range from -40°C to 85°C suitable for industrial environments.
- Compact size with dimensions of 6.5mm length, 10.65mm width, and 2mm height for space-constrained applications.
- Surface mount SOIC package facilitates automated assembly and manufacturing.
- Supply current is low at typically 3mA optimizing power consumption.
- Non-inverting output ensures correct data polarity in signal transmission.
Product Description
Renesas Electronics ICL3232ECBZ is a high-performance Line Transceiver IC designed for RS-232 interface applications. Its 3-state, non-inverting outputs combined with CMOS/TTL logic makes it an ideal choice for robust serial communication systems. This transceiver operates over a supply voltage range from 3.5V to 5.5V, accommodating both 3.3V and 5V power domains common in modern electronics.
Engineered for industrial and commercial electronics, the device maintains a propagation delay time of only 0.15 microseconds, ensuring timely data communication up to data rates of 1Mbps. The wide operating temperature range (-40°C to 85°C) supports use in harsh environments including automotive and industrial sectors.
The compact 16-pin SOIC surface-mount package measuring 6.5mm by 10.65mm with a height of 2mm enables efficient PCB layout and allows for automated mass production. A low supply current of approximately 3mA conserves energy making this transceiver suitable for battery-powered and low-power embedded systems.
Its design features a non-inverting output stage, ensuring signal polarity integrity during data transmission. The device supports dual transmit and receive channels with single-ended inputs, making it versatile for multiple line interface needs.
CMOS/TTL logic family operation. 3-state non-inverting output functionality. Wide voltage supply from 3.5V to 5.5V. Low 0.15μs maximum propagation delay time. Temperature range -40°C to 85°C for industrial-grade use. Compact 16-pin SOIC surface-mount package.
Low supply current of 3mA enhances efficiency. Supports RS-232 serial communication standards. Manufactured in China with high quality standards. Suitable for industrial, commercial, and embedded applications.
This line transceiver is optimized for use in electronics manufacturing, industrial automation, communication systems, and embedded device interfacing. Explore our comprehensive range of semiconductor components and interface ICs in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates over a supply voltage range from 3.5V to 5.5V, accommodating both 3.3V and 5V power domains.
The maximum propagation delay time for the ICL3232ECBZ is 0.15 microseconds, ensuring timely data communication.
It has a wide operating temperature range from -40°C to 85°C, making it suitable for industrial environments.
This model measures 6.5mm in length, 10.65mm in width, and 2mm in height, which is compact for space-constrained applications.
It features a 3-state, non-inverting output, ensuring correct data polarity during signal transmission.
The supply current is typically 3mA, optimizing power consumption for various applications.
This unit is packaged in a 16-pin SOIC surface-mount configuration, facilitating automated assembly and manufacturing.
It operates within the CMOS/TTL logic family, making it compatible with a wide range of electronic systems.
The ICL3232ECBZ supports single-ended inputs, allowing for versatile line interface configurations.
This line transceiver is optimized for use in electronics manufacturing, industrial automation, communication systems, and embedded device interfacing.
It supports data rates of up to 1Mbps, ensuring high-speed data transmission for RS-232 applications.
This model is manufactured in China, adhering to high-quality standards.
