DiodesZetex High Side Current Monitor 3-Pin SOT-23 Package ZXCT1008FTA
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | DiodesZetex |
| Height | 1.02mm |
| Length | 3.04mm |
| Model | ZXCT1008FTA |
| Mount Type | Surface |
| Bandwidth | 2MHz |
| Series | ZXCT1008 |
| Maximum Operating Temperature | 85°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Quiescent Current | 4μA |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Supply Voltage | 20V |
| Minimum Supply Voltage | 2.5V |
Key Features
- Operates with a low quiescent current of 4 microamperes.
- Supports bandwidth up to 2 MHz for dynamic current monitoring.
- Works with supply voltage range from 2.5 V to 20 V for flexible applications.
- Compact SOT-23 surface mount package with 3 pins for easy PCB integration.
- Operates reliably between -40°C and 85°C ambient temperatures.
- Suitable for integration in industrial and electronic power management systems.
- Manufactured in Germany complying with RoHS standards.
Product Description
DiodesZetex ZXCT1008FTA is a high side current sensing amplifier IC supplied in a compact 3-pin SOT-23 surface mount package. It offers a voltage output linearly proportional to the voltage drop across a low-value resistor placed in a high-current power rail, enabling precise current measurement in power electronics.
The device features a low quiescent current of just 4μA, enabling energy-efficient operation. It supports a wide bandwidth of 2 MHz that allows it to capture dynamic changes in current accurately. Operating supply voltage ranges from 2.5 V to 20 V, making it versatile for numerous electronic applications. The device is specified for operation in harsh environments with temperature tolerance from -40°C to 85°C.
Its compact size with a length of 3.04 mm and height of 1.02 mm ensures space-saving integration on PCBs. The SOT-23 package type is ideal for automated assembly and surface mounting techniques commonly used in manufacturing.
DiodesZetex ZXCT1008FTA complies with RoHS directives ensuring environmental safety and is manufactured in Germany with high-quality standards. Typical applications include current sensing in industrial machinery, power supply monitoring, HVAC systems, electronic control units in automotive and industrial sectors, and energy management devices.
The device’s precision current monitoring capability supports improved production efficiency and reliable system protection in complex electrical and electronic systems. Operates with a low quiescent current of 4 microamperes.
Bandwidth capability up to 2 MHz for high-frequency sensing. Wide supply voltage range from 2.5 V to 20 V. Compact 3-pin SOT-23 surface mount package. Reliable performance from -40°C to 85°C. Voltage output proportional to resistor voltage drop.
RoHS compliant with high manufacturing standards. Made in Germany. Explore more semiconductor current sensing amplifiers and sensor ICs at EnvMart for industrial, laboratory, automotive, and electronic applications.
Explore more products in our Electronic Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range from 2.5 V to 20 V, making it suitable for various electronic applications.
The ZXCT1008FTA features a low quiescent current of just 4 microamperes, enabling energy-efficient operation.
It supports a bandwidth of up to 2 MHz, allowing for accurate capture of dynamic changes in current.
The SOT-23 package has a length of 3.04 mm and a height of 1.02 mm, facilitating compact integration on PCBs.
This unit operates reliably between -40°C and 85°C, making it suitable for harsh environments.
It has a total of 3 pins, designed for surface mounting on PCBs.
Yes, this model complies with RoHS standards, ensuring environmental safety in its manufacturing.
Typical applications include current sensing in industrial machinery, power supply monitoring, and electronic control units in automotive and industrial sectors.
This model uses a surface mount type, which is ideal for automated assembly processes.
It provides a voltage output that is linearly proportional to the voltage drop across a low-value resistor in a high-current power rail.
This current monitor is manufactured in Germany, adhering to high manufacturing standards.
It belongs to the ZXCT1008 series, which includes other current sensing amplifiers.
