ROHM 2-Element Bi-Directional ESD Protection Diode, Surface Mount, 3-Pin SOT-23, 100 W Power Dissipation, 24 V ESD27VHYT116

Free Delivery in India | Lowest Global Shipping Charges

ROHM 2-Element Bi-Directional ESD Protection Diode, Surface Mount, 3-Pin SOT-23, 100 W Power Dissipation, 24 V ESD27VHYT116

Name: ROHM 2-Element Bi-Directional ESD Protection Diode, Surface Mount, 3-Pin SOT-23, 100 W Power Dissipation, 24 V ESD27VHYT116
Brand: ROHM
SKU: 308985
Price: 14.83 INR
Availability: InStock



Category ESD Protection Diode Brand ROHM Condition New

Specifications

Country of Origin	India
Brand	ROHM
Model	ESD27VHYT116
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-55°C
Standards/Approvals	IEC61000-4-2
Pin Count	3
Number of Elements per Chip	2
Clamping Voltage VC	24V
Direction Type	Bi-Directional
Minimum Breakdown Voltage Vbr	29.19V
Maximum Reverse Stand-off Voltage Vwm	24V
Peak Pulse Power Dissipation Pppm	100W
Maximum Reverse Leakage Current	100nA

Key Features

Delivers peak pulse power dissipation of 100 W suitable for transient voltage suppression.
Supports bidirectional ESD protection with IEC61000-4-2 compliance.
Has a reverse working maximum voltage (VRWM) of 24 V and breakdown voltage of 29.19 V.
Features low reverse leakage current of 100 nA and capacitance of 8 pF to minimize signal interference.
Operates over a temperature range from -55°C to 150°C ensuring durability in varied environments.
Small mold size suitable for high-density PCB applications with surface mount technology.
Provides ESD protection level up to ±30kV contact discharge for sensitive electronic devices.

Product Description

ROHM ESD27VHYT116 is a 2-element bi-directional ESD Protection Diode designed for surface mounting in a compact 3-pin SOT-23 package. It delivers excellent surge resistance and is ideal for protecting sensitive electronic devices against high transient voltages.

This diode features a peak pulse power dissipation of 100 watts, enabling robust transient voltage suppression for various electronics applications. Its bidirectional configuration ensures protection against both positive and negative ESD events, with compliance to IEC61000-4-2 standards, providing ±30kV contact discharge protection.

The ESD27VHYT116 has a maximum reverse stand-off voltage (VRWM) of 24 volts, and a minimum breakdown voltage (Vbr) of 29.19 volts, with a low reverse leakage current of 100 nA, reducing power loss and signal distortion. The capacitance at 8 pF helps maintain signal integrity in high-speed circuits.

Operating temperatures range from -55°C to 150°C, making it suitable for harsh industrial and commercial environments. The compact SOT-23 surface mount package supports high-density PCB layouts in telecommunications, computing, and consumer electronics.

Delivers peak pulse power dissipation of 100 W suitable for transient voltage suppression. Supports bidirectional ESD protection with IEC61000-4-2 compliance. Has a reverse working maximum voltage (VRWM) of 24 V and breakdown voltage of 29.19 V.

Features low reverse leakage current of 100 nA and capacitance of 8 pF to minimize signal interference. Operates over a temperature range from -55°C to 150°C ensuring durability in varied environments. Small mold size suitable for high-density PCB applications with surface mount technology.

Provides ESD protection level up to ±30kV contact discharge for sensitive electronic devices.

This diode is widely used in industrial, consumer electronics, telecommunications, and computing applications where ESD protection is critical to device reliability and performance.
