| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 0.6mm |
| Length | 2.5mm |
| Model | PLZ27A-HG3_A/H |
| Mount Type | Surface |
| Series | PLZ |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-219AC (MicroSMF) |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 200nA |
| Nominal Zener Voltage Vz | 25.52V |
| Zener Type | General Purpose |
| Maximum Zener Impedance | 45Ω |
Vishay PLZ27A-HG3_A/H Zener Diode is a single diode element silicon planar device designed for voltage regulation applications. It features a nominal Zener voltage of 25.52 V with a power dissipation rating of 500 mW, housed in a compact DO-219AC (MicroSMF) surface mount package suitable for space-constrained electronic assemblies.
Constructed with low leakage current characteristics and excellent stability, this device supports a test current of 5 mA and a maximum Zener impedance of 45 Ω, making it ideal for precision voltage applications. Its maximum reverse leakage current is only 200 nA.
The diode operates reliably within a temperature range of -55°C to 150°C, ensuring durability under harsh environmental conditions. It meets important standards including IEC 61000-4-2, IEC 61760-1, RoHS compliance, and automotive-grade AEC-Q101 certification for enhanced quality assurance.
The low profile MicroSMF package enables high-temperature soldering up to 260°C, supporting wave and reflow soldering methods, which is advantageous in modern surface mount technology. This general purpose Zener diode series PLZ delivers consistent performance in industrial, automotive, consumer electronics, and telecommunications applications.
Single silicon planar Zener diode for voltage regulation precision. Power dissipation rating of 500 mW enables stable operation. Low leakage current and maximum reverse leakage current of 200 nA. Compact MicroSMF DO-219AC surface mount package.
Wide operating temperature range from -55°C to 150°C. Compliance with IEC 61000-4-2, IEC 61760-1, RoHS, and automotive AEC-Q101 standards. Test current 5 mA with maximum Zener impedance of 45 Ω. High temperature soldering capability at 260°C suitable for modern PCB manufacturing.
This Zener diode is suitable for industrial, automotive, telecommunications, and general electronic equipment ensuring voltage stabilization and protection. Explore a wide range of semiconductor components and Zener Diodes on EnvMart for your electronics design and manufacturing needs.
