Teledyne LeCroy 100 MHz Bench Oscilloscope, 4-Channel USB Interface T3DSO1000

Teledyne LeCroy T3DSO1104 is a 100 MHz, 4-channel benchtop digital oscilloscope designed for precise electronic signal measurement and analysis. Featuring advanced high-speed display technology, it supports waveform capture rates up to 100,000 waveforms per second in normal operation, making it ideal for detailed electronic diagnostics.

This oscilloscope incorporates two ADCs operating at 1 GSa/s each, allowing flexible sample rate distribution based on channel usage. When all channels are active, sample rate is 500 MSa/s per channel, and up to 1 GSa/s on a single active channel, delivering excellent temporal resolution.

The instrument offers comprehensive digital triggering capabilities including edge, slope, pulse width, window, runt, interval, dropout timeout, and pattern triggers. Serial bus triggering and decoding is standard, supporting common protocols such as I2C, SPI, UART, RS232, CAN, and LIN, enabling detailed communication analysis.

Waveform display utilizes 256-level intensity grading and colour modes, enhancing signal visualization and interpretation. The device also records waveform history with a maximum length of 80,000 frames, allowing retrospective waveform analysis.

Compact yet robust, the T3DSO1104 features a bench-top form factor with physical dimensions of 151 mm height and 132.6 mm width, suitable for laboratory, industrial, and field use. It connects via USB interface and is powered by mains supply.

100 MHz bandwidth with 4 independent channels for complex signal acquisition. Maximum sample rate of 1 GSa/s with two high-speed ADCs. Digital triggering and multiple intelligent trigger types for precise capture. Serial bus triggering and decoding for popular communication protocols.

Waveform capture rates as high as 100,000 wfm/s (normal mode) and 400,000 wfm/s (sequence mode). 256-level intensity grading with color display enhances signal detail visibility. History waveform function supports recording of up to 80,000 waveform frames.

Compact dimensions ideal for benchtop use in test and measurement labs. USB connectivity for easy data transfer and integration.

The Teledyne LeCroy T3DSO1104 Oscilloscope is essential equipment in electronic design, medical research, education, physics, television repair, and various engineering and manufacturing applications where accurate waveform analysis is critical.
