RIGOL DS6000 Series Mixed Signal Oscilloscope | DS6104

The RIGOL DS6000 Series Mixed Signal Oscilloscope, available in the DS6104 model, is a high-performance digital measurement instrument designed for analysing high-speed electronic signals in research, development, manufacturing, and advanced laboratory environments. Its combination of wide bandwidth, powerful analysis functions, and flexible connectivity makes it suitable for engineers working with complex electronic systems.

The RIGOL DS6104 provides up to 1 GHz analogue bandwidth, enabling accurate measurement of high-frequency signals and fast device characteristics. It is suitable for analysing ESD events, digital video signals, communication circuits, clock signals, power electronics, and differential signals when used with a compatible differential probe accessory.

• Up to 1 GHz analogue bandwidth
• Four analogue input channels
• High-speed real-time signal acquisition
• Advanced triggering for isolating complex waveform events
• Protocol triggering and decoding for embedded-system analysis
• Hardware-based pass/fail testing
• Enhanced FFT spectrum analysis
• Automatic waveform measurements
• Mathematical waveform analysis functions
• Waveform recording and playback capabilities
• Search and navigation tools for long waveform records
• User-defined one-key quick-operation function
• Support for differential signal measurement with an optional probe
• Clear waveform visualisation for detailed signal inspection
• Connectivity options for data transfer and remote operation

The advanced triggering system helps engineers capture specific waveform conditions and intermittent faults that may otherwise be difficult to identify. Protocol decoding further simplifies the analysis of embedded communication signals, making the oscilloscope useful for microcontroller development, electronic control systems, and serial-bus troubleshooting.

Enhanced FFT analysis allows users to examine signals in the frequency domain and identify harmonics, interference, distortion, and unwanted noise. Hardware pass/fail testing supports repeatable product inspection and quality-control processes by automatically comparing captured waveforms against defined limits.

The user-defined one-key quick-operation feature provides convenient access to frequently used functions, helping reduce setup time during repetitive measurements. Its analysis, measurement, storage, and connectivity capabilities also support integration into professional laboratories and automated testing workflows.

Typical applications include high-speed digital circuit testing, ESD analysis, digital video testing, differential signal measurement, embedded-system debugging, communication equipment development, power-electronics validation, electronics manufacturing, product quality assurance, and engineering research.

Available Model: DS6104

Explore more RIGOL mixed signal oscilloscopes, digital oscilloscopes, electronic test instruments, and laboratory measurement equipment in the Oscilloscope category on EnvMart.
