Nexperia 40 V 3 A Low Forward Voltage MEGA Schottky Diode Surface Mount SOD-128 PMEG4030ETP,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 4mm |
| Model | PMEG4030ETP,115 |
| Width | 2.7mm |
| Mount Type | Surface |
| Series | PMEG4030ETP |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-128 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 3A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 23mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 490mV |
| Average forward current | IF(AV) ≤ 3 A |
| Reverse voltage | VR ≤ 40 V |
Key Features
- This diode features a maximum continuous forward current of 3 A for medium power applications.
- The peak reverse repetitive voltage is rated at 40 V for robust reverse voltage handling.
- Low forward voltage drop of 490 mV reduces power loss and heat generation.
- Encapsulated in a small SOD-128 surface-mount package suitable for space-constrained PCB layouts.
- Operating temperature range spans from -55°C to a maximum of 175°C for high reliability.
- Complies with automotive AEC-Q101 qualification for enhanced durability.
- Package dimensions are compact with length 4 mm, width 2.7 mm, height 1.1 mm for efficient board space usage.
- Peak non-repetitive forward surge current capability is 50 A to withstand transient spikes.
Product Description
Nexperia PMEG4030ETP,115 is a medium power low forward voltage MEGA Schottky barrier rectifier diode encapsulated in a compact and flat SOD-128 surface-mounted plastic package. It is engineered for high performance, high efficiency, and space-saving applications in industrial, automotive, and power electronics.
With a maximum continuous forward current of 3 A and a peak reverse repetitive voltage rating of 40 V, this single Schottky diode provides reliable voltage rectification with low forward voltage drop of 490 mV, which minimizes power dissipation and improves energy efficiency.
The diode’s operating temperature ranges from -55°C to a maximum junction temperature of 175°C, supporting performance in harsh thermal environments. It also benefits from AEC-Q101 qualification, ensuring automotive-grade reliability for electronic control units and power supplies.
The SOD-128 package measures 4 mm in length, 2.7 mm width, and 1.1 mm height, suitable for space-restricted PCB layouts. Its clip-bonding technology enhances power capability and robustness.
Key features such as a 50 A peak non-repetitive forward surge current and a 2-pin configuration simplify design requirements for applications in power management, battery protection, and voltage clamping in automotive, industrial, and consumer electronics.
Maximum continuous forward current: 3 A. Peak reverse repetitive voltage: 40 V. Forward voltage drop: 490 mV. Operating temperature: -55°C to 175°C. Package type: SOD-128 surface mount. Automotive AEC-Q101 qualified. Peak non-repetitive surge current: 50 A.
Compact size with length 4 mm, width 2.7 mm, height 1.1 mm. Single diode configuration with 2 pins.
This Schottky Diode is ideal for use in discrete semiconductor applications requiring efficient rectification, power management, and protection functions in automotive, industrial controls, and electronic device manufacturing.
Explore more semiconductor solutions and power management components at EnvMart for advanced electronic design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this diode is 3 A, suitable for medium power applications.
The peak reverse repetitive voltage rating is 40 V, allowing for robust reverse voltage handling.
The forward voltage drop is 490 mV, which helps to reduce power loss and heat generation.
The package dimensions are 4 mm in length, 2.7 mm in width, and 1.1 mm in height, making it compact for PCB layouts.
The operating temperature range spans from -55°C to a maximum of 175°C, ensuring high reliability in various environments.
The diode has a peak non-repetitive forward surge current capability of 50 A, allowing it to withstand transient spikes.
Yes, this diode complies with the automotive AEC-Q101 qualification, ensuring reliability for automotive electronic control units.
This model features a single diode configuration with 2 pins, simplifying design requirements.
The peak reverse current is rated at 23 mA, which is important for understanding its performance under reverse bias conditions.
This Schottky diode is suitable for applications in power management, battery protection, and voltage clamping in automotive and industrial electronics.
The rectifier type is Schottky, known for its low forward voltage drop and fast switching capabilities.
