Vishay 120 V 6 A Schottky Barrier Schottky DPAK Surface Mount Rectifier V6PW12HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Model | V6PW12HM3/I |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 6A |
| Peak Reverse Repetitive Voltage Vrrm | 120V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 0.62V |
Key Features
- Features Trench MOS Schottky technology for high efficiency and low forward voltage drop.
- Compact TO-252 (DPAK) package ensures low profile with a typical height of 1.3 mm.
- Suitable for low voltage, high frequency DC/DC converters and freewheeling diode applications.
- Operates reliably over a temperature range from -40°C to 175°C.
- Meets automotive standard AEC-Q101 and RoHS compliance for stringent quality and environmental safety.
- Designed for automated pick-and-place assembly processes.
- Offers high surge current capability with 100 A peak non-repetitive forward surge current.
- Low power dissipation and power losses ensure efficient operation.
Product Description
Vishay V6PW12HM3/I Schottky Barrier Rectifier is a high-performance surface mount semiconductor device optimized for electronic and power management applications. It features a robust 120 V peak reverse voltage rating and a continuous forward current of 6 A, making it suitable for demanding power rectification tasks in industrial, automotive, and electronic sectors.
The device utilizes Trench MOS Schottky technology, which significantly reduces forward voltage drop and improves energy efficiency, critical for high-frequency DC/DC converters and polarity protection circuits. Its TO-252 (DPAK) surface mount package offers a low-profile design with a typical height of 1.3 mm, aiding in compact PCB layouts.
This diode operates across a wide temperature range from -40°C to 175°C, ensuring reliability in harsh environmental conditions. Additionally, it has a high peak non-repetitive forward surge current rating of 100 A, ensuring durability against transient loads.
The V6PW12HM3/I meets automotive quality standards AEC-Q101 and RoHS compliance, underscoring its suitability for automotive electronics and environmentally conscious applications. It is designed for automated assembly processes, further enhancing manufacturing efficiency.
Trench MOS Schottky technology provides low forward voltage drop and high efficiency. Surface mount TO-252 package minimizes height and supports automated placement. Rated for 6 A continuous forward current and 120 V peak reverse voltage.
Wide operating temperature range from -40°C to 175°C. High surge current capacity with 100 A peak non-repetitive forward surge current. Compliant with automotive standard AEC-Q101 and environmental RoHS directives. Ideal for DC/DC converters, freewheeling diode, and polarity protection applications.
This Vishay Schottky Barrier Rectifier is widely used in power management for industrial controllers, automotive electronics, telecommunications equipment, and consumer electronics that require efficient, low-loss rectification. The compact TO-252 package allows for streamlined PCB design and enhanced thermal performance. Explore more Vishay semiconductor solutions and related electronic components on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 6 A.
The peak reverse repetitive voltage rating is 120 V.
It operates reliably over a temperature range from -40°C to 175°C.
This rectifier uses a TO-252 (DPAK) surface mount package.
The model has a peak non-repetitive forward surge current rating of 100 A.
It meets the automotive standard AEC-Q101.
Yes, it is RoHS compliant, ensuring adherence to environmental safety standards.
It is suitable for low voltage, high frequency DC/DC converters and freewheeling diode applications.
The maximum forward voltage drop is 0.62 V.
It utilizes Trench MOS Schottky technology, which reduces forward voltage drop and improves energy efficiency.
The country of origin for the V6PW12HM3/I is India.
This model is designed for surface mounting.
