Nexperia Schmitt Trigger Input Schmitt Trigger Inverter 3 Elements CMOS Logic IC Surface Mount 0.8-3.6 V 74AUP1G14GX4-Q100Z

Nexperia 74AUP1G14GX4-Q100Z Schmitt Trigger Input Schmitt Trigger Inverter 3 Elements CMOS logic IC operates with a supply voltage range of 0.8 V to 3.6 V. It is designed to deliver very low static and dynamic power consumption while providing reliable performance across industrial temperature ranges from -55°C to 125°C.

Featuring three Schmitt Trigger input elements per chip, this surface mount device measures 650μm by 650μm with a height of 350μm. It boasts a maximum propagation delay time at capacitive load of 4 ns, making it suitable for high-speed switching applications.

The device's IOFF circuitry facilitates partial power down mode operation, disabling the output to prevent potentially damaging backflow current during power-down states. It offers high noise immunity and is tolerant to input overvoltages up to 3.6 V, ensuring robust functionality in noisy environments.

Low static current consumption, typically not exceeding 0.9 μA, contributes to energy efficiency in battery-powered and low-voltage applications. The IC conforms to RoHS and JEDEC standards, assuring compliance with environmental and quality regulations.

This Schmitt Trigger inverter IC is ideal for industrial, laboratory, and electronic manufacturing use cases including signal conditioning, waveform shaping, astable multivibrators, monostable multivibrators, and other timing-related applications in semiconductor and electronics projects.

Features three Schmitt Trigger input elements in a single inverter IC. Operates with supply voltage from 0.8 V up to 3.6 V for wide application range. Surface mount package with compact dimensions: 650μm length and width, 350μm height.

Low static power consumption with a maximum ICC of 0.9 μA. High noise immunity and overvoltage tolerant inputs up to 3.6 V. Maximum propagation delay time at CL is 4 ns, supporting fast switching speeds. Wide operating temperature range from -55°C to 125°C suitable for industrial environments.

IOFF circuitry provides partial power-down mode to prevent damaging backflow current. Complies with RoHS and JEDEC standards ensuring quality and environmental safety. Applications include waveform shaping, monostable and astable multivibrator circuits.
