Nexperia Schmitt Trigger Input Inverter 1 Element 5-Pin TSSOP 1.65 to 5.5 V 74LVC1G14GW,125

Nexperia 74LVC1G14GW,125 Schmitt Trigger Input Inverter is a low-voltage CMOS logic IC designed for precise signal conditioning and noise immunity in electronic circuits. Featuring a single inverter gate with Schmitt trigger input, this device provides clean transitions and supports operating voltage from 1.65 to 5.5 V.

This logic inverter is housed in a compact 5-pin TSSOP surface mount package, measuring 2.25 mm in length, 1.35 mm in width, and 1 mm in height. Designed to withstand harsh environments, it operates reliably across a temperature range from -40°C to 125°C.

The maximum propagation delay time is 8.5 ns at typical capacitive load, making it suitable for medium-speed logic applications. The maximum high-level output current is -32 mA and low-level output current is 32 mA, supporting efficient drive capability for downstream circuits.

Widely compatible with input LVTTL/TTL logic levels and output LVCMOS signals, it integrates seamlessly in modern electronic designs. This inverter is part of the 74LVC1G14 product family known for CMOS low-voltage performance.

Applications include industrial control systems, telecommunications equipment, signal conditioning, and embedded electronic modules requiring stable logic inversion with noise immunity.

Operating voltage range of 1.65 to 5.5 V ensures broad compatibility. Single inverter gate with Schmitt trigger input for clean signal transitions. Compact TSSOP 5-pin surface mount package facilitates PCB space saving. Temperature range from -40°C up to 125°C provides durability in tough conditions.

Maximum propagation delay of 8.5 ns supports efficient logic operation. Compatible with LVTTL/TTL inputs and LVCMOS outputs for flexible interfacing. High and low level output currents of -32mA and 32mA for effective drive capacity.

Part of the 74LVC1G14 series ensures consistent reliability and quality.

Choose the Nexperia 74LVC1G14GW,125 inverter for robust logic inversion needs in industrial, electronic, and manufacturing applications. Explore the full range of semiconductor ICs and inverters available at EnvMart for your projects.

Explore more products in our Inverter ICs category.
