Nexperia Small Signal NPN Transistor 200 mA 40 V 3-Pin SOT-23 PMBT3904,215

Nexperia PMBT3904,215 transistor is a small signal NPN bipolar transistor designed for low power and high frequency switching applications. It supports a maximum DC collector current of 200 mA and can withstand collector-emitter voltages up to 40 V, making it suitable for various electronic circuit designs and signal amplification tasks.

The device comes in a compact 3-pin SOT-23 surface mount package, which is ideal for space-constrained PCB layouts. Its maximum power dissipation rating of 250 mW ensures reliable operation when driven within specified limits. The transistor configuration is single, optimized for discrete semiconductor use in analog and digital circuits.

This transistor offers a high minimum DC current gain of 100 and a maximum transition frequency of 300 MHz, allowing efficient amplification and switching in communication, industrial, and consumer electronic devices. It operates robustly across a broad temperature range from -65°C to 150°C, supporting applications in harsh environmental conditions.

Dimensions of the package are 3 mm length, 2.5 mm width, and 1.1 mm height, enabling compatibility with modern automated assembly processes. Additional electrical maximum voltage ratings include collector-base voltage up to 60 V and emitter-base voltage of 6 V.

It is widely used in electronic component assembly, power connectors, and semiconductor device applications in industrial, commercial, and consumer product environments. Supports maximum collector current of 200 mA for low power switching.

Maximum collector-emitter voltage of 40 V suitable for various electronic circuits. Compact SOT-23 surface mount package with 3 pins for easy PCB mounting. Maximum power dissipation of 250 mW ensures stable operation in applications.

High minimum DC current gain (hFE) of 100 for efficient amplification. Broad operating temperature range from -65°C to 150°C. Maximum transition frequency (ft) of 300 MHz for high-speed switching. Manufactured in Malaysia ensuring quality and reliability.

This product is ideal for industrial electronics, communication devices manufacturing, consumer electronics, and laboratory applications. Explore other quality Bipolar Transistors and related semiconductor products on EnvMart.
