Nexperia Schottky Diode 20 V 2 A Surface Mount SOD-323 2-Pin PMEG2020AEA,115
Specifications
| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 1.05mm |
| Length | 1.8mm |
| Model | PMEG2020AEA,115 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | PMEG2020AEA |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 2A |
| Peak Reverse Repetitive Voltage Vrrm | 20V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 200μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 9A |
| Maximum Forward Voltage Vf | 525mV |
Key Features
- Surface mount diode type for compact PCB designs.
- Maximum continuous forward current of 2 A for stable operation.
- Peak reverse repetitive voltage rated at 20 V for protection against voltage spikes.
- Ultra-small SOD-323 package with dimensions 1.8 mm length, 1.35 mm width, and 1.05 mm height.
- Low forward voltage drop of 525 mV improves efficiency and reduces heat dissipation.
- Peak non-repetitive forward surge current of 9 A supports transient high current conditions.
- Operating temperature range from -65°C to 150°C suitable for automotive and industrial environments.
- Automotive grade compliant with AEC-Q101 standard ensuring reliability.
Product Description
Nexperia PMEG2020AEA,115 Schottky Diode is a compact, high-efficiency surface mount diode suitable for low-voltage rectification needs in electronic circuits. This diode features a maximum continuous forward current of 2 amperes and a peak reverse repetitive voltage of 20 volts, enabling robust performance in power applications.
The device comes in a small SOD-323 2-pin package with dimensions of 1.8 mm length, 1.35 mm width, and 1.05 mm height, making it ideal for space-constrained PCB layouts. It has a low forward voltage drop of 525 mV, which helps to minimize power loss and reduce thermal stress during operation. The diode can also withstand a peak non-repetitive forward surge current of 9 A, providing protection during transient current spikes.
Operating across a wide temperature range from -65°C to 150°C, this schottky diode meets the automotive AEC-Q101 standard, ensuring durability and reliability for automotive and industrial applications. The single diode configuration with 2 pins simplifies installation and circuit design.
Typical applications include power rectification, voltage clamping, and reverse polarity protection in automotive electronics, power supplies, battery management, and general semiconductor circuits. The product is manufactured in China under strict industry standards to guarantee quality and consistency.
Surface mount diode type for compact PCB designs. Maximum continuous forward current of 2 A for stable operation. Peak reverse repetitive voltage rated at 20 V for protection against voltage spikes. Ultra-small SOD-323 package with dimensions 1.8 mm length, 1.35 mm width, and 1.05 mm height.
Low forward voltage drop of 525 mV improves efficiency and reduces heat dissipation. Peak non-repetitive forward surge current of 9 A supports transient high current conditions. Operating temperature range from -65°C to 150°C suitable for automotive and industrial environments.
Automotive grade compliant with AEC-Q101 standard ensuring reliability. Single diode configuration with 2 pins for simple circuit integration. Manufactured in China to strict quality standards. Explore more in our semiconductor diode catalog for advanced circuit design and automation solutions available at EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 2 A, ensuring stable operation in various applications.
This diode has a peak reverse repetitive voltage rating of 20 V, providing protection against voltage spikes.
The SOD-323 package dimensions are 1.8 mm in length, 1.35 mm in width, and 1.05 mm in height, making it suitable for compact PCB designs.
The forward voltage drop for this model is 525 mV, which helps to improve efficiency and reduce heat dissipation during operation.
This diode can withstand a peak non-repetitive forward surge current of 9 A, supporting transient high current conditions.
The operating temperature range for this Schottky diode is from -65°C to 150°C, making it suitable for automotive and industrial environments.
Yes, this diode is compliant with the AEC-Q101 standard, ensuring reliability for automotive applications.
This model features a single diode configuration with 2 pins, simplifying installation and circuit design.
It uses a surface mount type, which is ideal for compact designs on printed circuit boards.
The peak reverse current for this diode is rated at 200 μA, which is important for understanding its leakage characteristics.
This Schottky diode is manufactured in China under strict industry standards to ensure quality and consistency.
Typical applications include power rectification, voltage clamping, and reverse polarity protection in automotive electronics and power supplies.
