Texas Instruments 6-Channel Inverting TTL Hex Buffer 14-Pin SOIC SN74HCT04D
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 2mm |
| Length | 10.5mm |
| Model | SN74HCT04D |
| Mount Type | Surface |
| Output type | TTL |
| Series | SN74HCT04 |
| Input Type | CMOS |
| Maximum Operating Temperature | 150°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -65°C |
| Polarity | Inverting |
| Number Of Channels | 6 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | 74HC |
| Logic Function | Inverter |
| Minimum Supply Voltage | 4.5V |
| Maximum Propagation Delay Time @ CL | 25ns |
| Supply Current | 40μA |
Key Features
- Operates with supply voltage range from 4.5V to 5.5V.
- Maximum propagation delay time of 25 nanoseconds ensures fast performance.
- Low supply current consumption of 40 microamperes for efficient power usage.
- Suitable for surface mount applications with a compact SOIC package type.
- Temperature range from -65°C to 150°C supports extended industrial use.
- Features 6 inverting channels with TTL output polarity.
- RoHS compliant with environmentally friendly manufacturing standards.
- Pin count of 14 ensures compatibility with standard logic circuits.
Product Description
Texas Instruments SN74HCT04D is a 6-channel inverting TTL hex buffer designed for use in various electronic and industrial applications requiring reliable logic inversion and signal buffering. It features CMOS input matching and TTL output for efficient interfacing in digital circuits.
The device operates at a minimum supply voltage of 4.5 volts and a maximum of 5.5 volts, delivering a maximum propagation delay time of 25 nanoseconds at a typical load. Its low supply current of 40 microamperes ensures power-efficient operation suitable for battery-powered and low-power circuits.
Housed in a compact 14-pin SOIC surface mount package with dimensions of 10.5 mm length and 2 mm height, the SN74HCT04D is ideal for dense PCB designs. It supports a wide operating temperature range from -65°C to 150°C, allowing use in demanding industrial environments.
This hex buffer features 6 inverting channels, offering high-performance signal inversion with TTL output polarity, making it perfect for logic level translation and buffering in semiconductor and digital electronics projects. Being RoHS compliant, this IC adheres to environmental standards.
Operates within 4.5V to 5.5V supply voltage range. Six inverting channels provide versatile logic buffering. Low power consumption with 40μA supply current. Maximum propagation delay of 25ns for fast signal processing. Compact SOIC package designed for surface mount PCB assembly.
Wide operating temperature from -65°C to 150°C supports harsh environments. 14-pin configuration aligns with standard digital logic IC layouts. RoHS compliant, ensuring environmental safety and standards compliance.
This product is widely used in industrial, laboratory, and commercial electronic applications for inverting signal processing, digital logic interfacing, and buffering tasks. It provides reliable performance for semiconductor circuit designs and electronic component integrations.
Explore more Texas Instruments semiconductor products and logic ICs on EnvMart to find compatible components tailored to your precise technical requirements.
Explore more products in our Buffers category.
