Texas Instruments 4-Channel 3 State Quad Bus Buffer, 14-Pin TSSOP SN74LVC125APW
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 2mm |
| Length | 10.5mm |
| Model | SN74LVC125APW |
| Mount Type | Surface |
| Output type | 3 State |
| Series | SN74LVC125A |
| Input Type | CMOS |
| Maximum Operating Temperature | 150°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -65°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Maximum Supply Voltage | 3.6V |
| Logic Family | 74LVC |
| Logic Function | Buffer |
| Minimum Supply Voltage | 1.65V |
| Maximum High Level Output Current | -24mA |
| Maximum Low Level Output Current | 24mA |
Key Features
- Supports four channels with tri-state output functionality for bus interfacing.
- Features a compact 14-pin TSSOP package suitable for surface mount applications.
- Operates with a minimum supply voltage of 1.65V and maximum of 3.6V.
- Has a wide operating temperature range from -65°C to 150°C for industrial environments.
- Provides a maximum high level output current of -24mA and low level output current of 24mA.
- Built with the 74LVC logic family CMOS technology ensuring low power consumption.
- Complies with RoHS standards ensuring environmental safety.
- Typical dimensions include a length of 10.5mm and height of 2mm for efficient board space use.
Product Description
Texas Instruments SN74LVC125APW is a 4-channel 3-state quad bus buffer designed with a 14-pin TSSOP package for surface mounting. This device operates under the 74LVC logic family with CMOS input technology providing efficient buffering for digital circuits.
The buffer supports four independent channels, each with tri-state output functionality, enabling effective bus control in complex digital systems. Its supply voltage ranges from 1.65V minimum to 3.6V maximum, making it well suited for low voltage applications.
Operating temperature spans from -65°C to 150°C, making it robust for industrial, commercial, and laboratory environments. The maximum output currents are ±24mA, providing strong driving capability.
The compact 14-pin TSSOP package format with a length of 10.5mm and height of 2mm allows easy integration into printed circuit boards where space is limited. Compliance with RoHS standards assures environmentally-friendly manufacturing processes.
This component is ideal for electronic component assemblies requiring precise logic buffering, such as in laboratory instruments, instrumentation systems, industrial automation, and communication interfaces.
Offers four buffered channels supporting tri-state outputs to manage high impedance bus lines effectively. Small form factor reduces PCB footprint without compromising performance. Wide voltage and temperature range enhances reliability across diverse operating conditions.
Low power consumption through CMOS technology helps extend device longevity. Suitable for use in measurement and control systems, embedded logic circuits, and digital signal processing. RoHS compliance ensures adherence to global environmental directives.
