Panasonic Shielded Wirewound Surface Mount Inductor with Metal Composite Core 10 μH ±20% 5.2 A Idc ETQP4M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 4.8mm |
| Length | 6.4mm |
| Model | ETQP4M |
| Depth | 6mm |
| Packaging | Tape & Reel |
| Series | ETQP4M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 10μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 5.2A |
| Pin Count | 2 |
| Maximum DC Resistance | 44.44mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a metal composite core for high heat and vibration resistance.
- Surface mount package with tape & reel packaging for efficient PCB assembly.
- Supports operating temperatures from -40°C to 150°C.
- Features low audible noise and excellent inductance stability for high reliability.
- Shielded design reduces electromagnetic interference for sensitive applications.
- Complies with RoHS and automotive AEC-Q200 standards.
- Maximum DC resistance of 44.44 mΩ ensures efficient operation.
- Maximum self-resonant frequency is 100 kHz, suitable for noise filtering in drive circuitry.
Product Description
Panasonic ETQP4M shielded wirewound surface mount inductor with a metal composite core offers robust performance with 10 μH inductance rated at ±20% tolerance and a maximum DC current of 5.2 A. This component is designed for high heat resistance and vibration endurance, making it well suited for demanding industrial and automotive electronics environments.
The inductor features a shielded design that minimizes electromagnetic interference, ensuring signal integrity in sensitive electronic circuits. Its compact surface mount package with tape and reel facilitates automated PCB assembly. The metal composite core provides excellent inductance stability and low audible noise, critical for noise filtering applications in power and drive circuitry.
Operating temperature range is from -40°C to 150°C, compliant with stringent automotive AEC-Q200 standards, and it meets RoHS environmental compliance requirements. The maximum DC resistance is 44.44 mΩ, supporting efficient current flow with minimal losses.
Physical dimensions include a length of 6.4 mm, height of 4.8 mm, and depth of 6 mm, offering a balance between size and performance suitable for compact electronic designs. Its maximum self-resonant frequency of 100 kHz enables effective noise filtering and peak current handling capability.
Constructed with metal composite core for durability and high heat performance. Shielded wirewound design reduces electrical noise and interference. Surface mount with tape and reel packaging simplifies manufacturing. Operates reliably under automotive-grade temperature ranges (-40°C to 150°C).
Certified RoHS compliant and meets AEC-Q200 automotive standards. Low DC resistance of 44.44 mΩ reduces power loss. Robust inductance stability with ±20% tolerance. Compact dimensions enable use in space-limited applications.
High maximum DC current rating of 5.2 A supports peak loads. Ideal for noise filtering in industrial, automotive, and general electronics use cases. Explore the full range of Surface Mount Inductors from Panasonic and related electronic components for enhanced circuit performance and reliability on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 10 μH with a tolerance of ±20%.
It has a maximum DC current rating of 5.2 A, suitable for handling peak loads in various applications.
The dimensions are 6.4 mm in length, 4.8 mm in height, and 6 mm in depth.
The maximum operating temperature is 150°C, making it suitable for high-temperature applications.
It is constructed with a metal composite core, providing high heat and vibration resistance.
The shielded design reduces electromagnetic interference, ensuring signal integrity in sensitive applications.
The maximum self-resonant frequency is 100 kHz, which is effective for noise filtering in drive circuitry.
This inductor complies with RoHS and automotive AEC-Q200 standards, ensuring environmental and automotive reliability.
It is packaged in a tape and reel format, facilitating efficient automated PCB assembly.
The maximum DC resistance is 44.44 mΩ, which supports efficient operation with minimal power loss.
The termination style is surface mount, suitable for various electronic applications.
This inductor is ideal for noise filtering in industrial, automotive, and general electronics applications.
