Wolfspeed 650 V 20 A Schottky Diode 3-Pin DPAK Surface Mount Z-Rec Series C3D06065E
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wolfspeed |
| Height | 2.38mm |
| Length | 7.34mm |
| Model | C3D06065E |
| Width | 7.51mm |
| Mount Type | Surface |
| Series | Z-Rec |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 650V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 100μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 540A |
| Maximum Forward Voltage Vf | 2.4V |
Key Features
- Surface mount package type TO-252 offers compact and reliable installation.
- Maximum continuous forward current of 20 A supports high current conditions.
- Peak reverse repetitive voltage is rated at 650 V for robust voltage tolerance.
- Extremely fast switching speeds minimize power losses in high frequency circuits.
- Wide operating temperature range from -55°C to 175°C ensures durability.
- Peak non-repetitive forward surge current up to 540 A allows transient handling.
- Positive temperature coefficient forward voltage enables parallel device use without thermal runaway.
- Optimized for PFC boost diode applications in power supplies and inverters.
Product Description
Wolfspeed C3D06065E Schottky Diode 3-Pin DPAK is a silicon carbide diode engineered to deliver excellent performance in high voltage and high current industrial and automotive applications. The device offers a maximum continuous forward current of 20 A and a peak reverse repetitive voltage of 650 V, making it suitable for demanding power electronics environments.
This diode is fabricated using Wolfspeed's advanced Z-Rec™ Silicon Carbide technology which provides significantly higher breakdown voltage, superior thermal conductivity, and improved efficiency compared to traditional silicon-based Schottky diodes. The low forward voltage and zero reverse recovery current contribute to reduced switching losses and improved system efficiency.
The 3-pin DPAK surface mount package provides a compact footprint and ease of integration on printed circuit boards. Its wide operating temperature range from -55°C to 175°C allows reliable operation in harsh thermal conditions.
This diode also features a peak non-repetitive forward surge current of 540 A, making it resilient to transient electrical stresses. With a positive temperature coefficient of forward voltage, multiple devices can be run in parallel without risk of thermal runaway, simplifying circuit design.
Compliance with the automotive standard AEC-Q101 certifies its suitability for automotive applications. Typical uses include switch-mode power supplies, high-speed inverters, and power factor correction (PFC) circuits.
Surface mount TO-252 package with 3 pins. Maximum forward current: 20 A. Peak repetitive reverse voltage: 650 V. Zero reverse recovery current ensures minimal switching losses. Temperature independent switching behavior.
Compact device dimensions: 7.34 x 7.51 x 2.38 mm (L x W x H). Automotive AEC-Q101 qualified device.
This Wolfspeed diode represents a high-performance power component, ideal for industrial, automotive, and commercial electronics requiring efficient, reliable rectification with minimal power loss. Browse the full range of Wolfspeed Schottky Diodes on EnvMart for advanced power electronics solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the C3D06065E Schottky diode is 20 A.
This model has a peak reverse repetitive voltage rating of 650 V.
The diode operates within a wide temperature range from -55°C to 175°C.
The C3D06065E is housed in a TO-252 surface mount package.
The AEC-Q101 qualification indicates that this diode meets automotive standards, making it suitable for automotive applications.
The peak non-repetitive forward surge current for this diode is rated at 540 A.
The dimensions of this diode are 7.34 mm in length, 7.51 mm in width, and 2.38 mm in height.
This model is a Schottky rectifier, which is known for its fast switching speeds and low forward voltage.
The diode features a positive temperature coefficient for forward voltage, allowing multiple devices to be used in parallel without thermal runaway.
The peak reverse current for this diode is specified at 100 μA.
This diode is optimized for power factor correction (PFC) boost diode applications in power supplies and inverters.
The C3D06065E has a 3-pin configuration, suitable for surface mount applications.
