Panasonic E-S1 Surge Absorber Varistor 390 V, Capacitance 800 pF, Clamping Voltage 1815 V, Current 100 A, Model ERZE14A391S1
Specifications
| Country of Origin | Indonesia |
|---|---|
| Diameter | 16.5mm |
| Brand | Panasonic |
| THICKNESS | 6.2mm |
| Length | 24mm |
| Model | ERZE14A391S1 |
| Depth | 6.2mm |
| Packaging | Bulk |
| Series | E-S1 |
| Maximum Operating Temperature | 125°C |
| Capacitance | 800pF |
| Minimum Operating Temperature | -40°C |
| Maximum dc Voltage | 895V dc |
| Pin Count | 2 |
| Termination Style | Straight Lead |
| Lead Pitch | 10mm |
| Maximum AC Voltage | 680V ac |
| Clamping Voltage VC | 1815V |
| Clamping Current | 100A |
| Maximum Surge Current | 7.5kA |
| Varistor Voltage | 390 V |
Key Features
- Compact and high capability for absorbing transient overvoltage up to 125°C operating temperature.
- Clamping voltage of 1815 V ensures robust surge protection.
- Nominal clamping current of 100 A with maximum surge current capacity of 7.5 kA.
- Suitable for protecting transistors, diodes, ICs, thyristors, and triacs in electronic equipment.
- Features a 16.5 mm diameter with dimensions 24 mm length and 6.2 mm thickness for compact installations.
- Designed with straight lead termination and 10 mm lead pitch for easy circuit integration.
- Complies with multiple international standards including IEC62368-1, IEC60950-1, UL, and VDE approvals.
- Ideal for surge protection in consumer electronics, communication devices, measuring instruments, and home appliances.
Product Description
Panasonic ERZE14A391S1 surge absorber varistor provides high reliability transient voltage suppression with a varistor voltage rating of 390 V and capacitance of 800 pF. It is engineered for enhanced surge energy absorption withstanding high surge currents up to 7.5 kA at elevated temperature conditions up to 125°C.
This series E-S1 varistor is compact with a 16.5 mm diameter and overall size optimized for installation in densely packed electronic assemblies. The device features a straight lead termination and 10 mm lead pitch for standard PCB mounting.
Adhering to strict international standards such as IEC62368-1, IEC60950-1, UL1449, and VDE IEC61051-1 ensures compatibility and safety across diverse applications.
The high clamping voltage of 1815 V and current rating of 100 A make this Varistor suitable for surge protection of sensitive semiconductor devices including transistors, diodes, ICs, thyristors, and triacs frequently used in consumer electronic, communication, measuring, control, and household appliance equipment.
This bulk packaged component is manufactured in Indonesia and represents a robust solution for managing transient and surge voltages in power and signal lines, contributing to electronic circuit durability and reliability under transient overvoltage conditions.
Compact design with high surge current withstand capability. Wide temperature operating range from -40°C to 125°C. Comprehensive global certification for diverse industrial and consumer applications. Bulk packaging optimized for assembly line uses and mass production.
Widely compatible with various surge protection schemes in electronic circuits. Manufactured to ensure consistent quality and performance standards. Explore more electronic components and surge protection devices at EnvMart for reliable industrial and consumer electronics solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum surge current capacity of this varistor is 7.5 kA.
The clamping voltage of this model is 1815 V.
It has a capacitance rating of 800 pF.
This varistor has a diameter of 16.5 mm, a length of 24 mm, and a thickness of 6.2 mm.
The operating temperature range is from -40°C to 125°C.
It features a straight lead termination style with a lead pitch of 10 mm.
It complies with IEC62368-1, IEC60950-1, UL1449, and VDE IEC61051-1 standards.
The varistor voltage rating is 390 V.
It is suitable for protecting transistors, diodes, ICs, thyristors, and triacs in various electronic equipment.
The maximum DC voltage rating is 895 V.
This component is packaged in bulk, optimized for assembly line uses.
It is manufactured in Indonesia.
