Bourns Shielded Wirewound Surface Mount Inductor with Ferrite Core 470μH ±20% 800mA Idc Q:13 SRN1060

Free Delivery in India | Lowest Global Shipping Charges

Bourns Shielded Wirewound Surface Mount Inductor with Ferrite Core 470μH ±20% 800mA Idc Q:13 SRN1060

Name: Bourns Shielded Wirewound Surface Mount Inductor with Ferrite Core 470μH ±20% 800mA Idc Q:13 SRN1060
Brand: BOURNS
SKU: 368114
Price: 0.59 USD
Availability: InStock



Category Surface Mount Inductors Brand BOURNS Condition New

Specifications

Country of Origin	India
Brand	Bourns
Height	6mm
Length	9.8mm
Model	SRN1060
Depth	10mm
Packaging	Reel
Series	SRN1060
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	470μH
Standards/Approvals	RoHS
Package/Case	1060
Maximum DC Current	800mA
Pin Count	2
Maximum DC Resistance	950mΩ
Inductance Tolerance	±20 %
Termination Style	Solder
Maximum Self Resonant Frequency	2MHz
Minimum Quality Factor	13
Inductor Construction	Wirewound

Key Features

Wirewound construction with ferrite core provides stable inductance.
Operating temperature ranges from -40°C to 125°C ensuring reliability in harsh conditions.
Semi magnetically shielded design minimizes electromagnetic interference.
Compact 1060 package size of 9.8mm length, 6mm height, and 10mm depth for surface mounting.
RoHS compliant with solder termination style for ease of PCB assembly.
Offers a minimum quality factor (Q) of 13 and maximum self-resonant frequency of 2MHz.
Maximum DC resistance is 950mΩ ensuring low power loss during operation.
Packaged on reels suitable for automated assembly processes.

Product Description

Bourns SRN1060 model is a shielded wirewound surface mount inductor designed with a ferrite core, offering an inductance of 470μH with ±20% tolerance. It supports a maximum DC current of 800mA and has a quality factor (Q) of 13, making it suitable for efficient power management and signal filtering in electronic circuits.

Constructed with wirewound technology and molded for durability, this surface mount inductor is housed in a compact 1060 package case measuring 9.8mm in length, 6mm in height, and 10mm in depth. The semi-magnetic shielding reduces electromagnetic interference, ensuring better performance in sensitive applications.

Rated for operation from -40°C up to 125°C, the inductor supports a maximum DC resistance of 950mΩ and a self-resonant frequency up to 2MHz. Its solder termination style is optimized for soldering onto printed circuit boards in automated production lines. Compliant with RoHS standards, it meets environmental and safety regulations.

Typical applications include DC/DC converters, notebook computers, digital video cameras, televisions, and LCD displays where compact and reliable inductors are essential for power and signal integrity.

Wirewound construction with ferrite core provides stable inductance. Operating temperature range of -40°C to 125°C ensures durability. Semi magnetically shielded design minimizes electromagnetic interference. Compact 1060 package for surface mounting on PCBs.

RoHS compliant with solder termination for easy assembly. High quality factor (Q) of 13 and self-resonant frequency of 2MHz. Low maximum DC resistance of 950mΩ reduces power loss. Packaged on reels for automated insertions.

This Bourns SRN1060 inductor is ideal for industrial, telecommunications, computer, and consumer electronics applications requiring high reliability and electrical performance. Explore additional Surface Mount Inductors and electronic passive components in EnvMart catalog for your precise engineering requirements.
