Display Visions Display Backlight Green and Red LED 20 Pins EA LED36x28-GR

Display Visions EA LED36x28-GR display backlight is designed as part of the EA DOG series targeting compact electronic display applications requiring efficient backlighting solutions. This model utilizes green and red LED backlight technology with 20 electrical pins, enabling secure PCB integration without requiring additional mounting hardware. The display backlight unit measures 36 mm in width and supports operation on 3.3 V systems without auxiliary power supply, making it ideal for low power embedded electronics.

Equipped with an SSD1803A controller featuring integrated graphic RAM, it provides high contrast visualization on a supertwist LCD panel. The ultra-flat form factor stands at 2.0 mm thickness without backlight, and 5.8 mm including LED backlighting, fitting well within compact device envelopes.

The EA LED36x28-GR offers multiple interface options including 4-bit, 8-bit SPI, and I²C, facilitating flexible integration with microcontroller-based designs in industrial, instrumentation, and consumer electronics domains. The product is RoHS compliant and manufactured in China, ensuring adherence to environmental standards.

The unit is ideal for electronic displays requiring colored backlighting, particularly green and red, improving readability under varying ambient lighting conditions. Its direct PCB solder design allows for reliable mechanical and electrical stability in demanding environments.

Utilizes LED backlight technology for efficient illumination. Comprises 20 pins for reliable electrical connection. Backlight colors are green and red, enhancing display visibility. Compact width design of 36 millimeters suitable for small displays.

Parts of the EA DOGS104x-A series for versatile applications. Designed for easy PCB soldering installation without mounting. Operates on low voltage systems without auxiliary power requirements. Integrates a high contrast LCD supertwist display with SSD1803A controller and graphic RAM.

This product suits electronic components, industrial automation displays, instrumentation panels, and other embedded systems where high visibility and compact backlighting solutions are necessary. It is part of the Display Visions brand reputed for specialized Display Backlighting modules.
