Winslow Straight Through Hole Mount 2.54 mm Pitch IC Socket Adapter SSOP to DIP W9588RC
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Winslow |
| Orientation | Straight |
| Model | W9588RC |
| Mount Type | Through Hole |
| Housing Material | FR4 |
| Contact Material | Brass |
| Pitch | 2.54mm |
| Contact Plating | Tin over Nickel |
| Connection Gender A | Female |
| Number of Contacts A | 36 |
| Connection Gender B | Male |
| Connection A | SSOP |
| Connection B | DIP |
Key Features
- The adapter supports 36 contacts on both SSOP and DIP sides ensuring full pin mapping.
- Connection gender is female on the SSOP side and male on the DIP side enabling secure interfacing.
- Contact plating consists of tin over nickel ensuring reliable conductivity.
- Contacts are made of brass for durability and performance.
- The housing material is FR4 providing mechanical strength and insulation.
- Designed for through hole mounting with a straight orientation for PCB installation.
- No specific certifications or approvals are applicable.
- Ideal for converting Small Outline packages to dual in line package format to reduce redesign costs.
Product Description
Winslow W9588RC is a high-quality IC Socket Adapter designed for converting SSOP packages to dual in line package (DIP) format with a 2.54 mm pitch. This straight through hole mount adapter accommodates 36 female contacts on the SSOP side and 36 male contacts on the DIP side, making it suitable for adaptation between SOP/SSOP/TSOP/TSSOP/MSOP/QSOP packages and DIP layouts.
The adapter's contacts are constructed of brass with tin over nickel plating that ensures excellent electrical conductivity and resistance to corrosion, extending the product's lifespan under industrial and manufacturing conditions. The housing material is FR4, providing mechanical strength and insulation during PCB assembly.
Its through hole mounting and straight orientation offer stability and ease of installation in electronic circuit boards, commonly used in electronic component prototyping, testing, and repair applications. The lack of specific standards or approvals indicates suitability primarily for engineering and development use cases where customization is essential.
Made in the United Kingdom, this adapter exemplifies quality manufacturing aimed at electronic components, power, and connector sectors, facilitating conversion and compatibility of integrated circuit packages.
The adapter supports 36 contacts on both SSOP and DIP sides ensuring full pin mapping. Connection gender female on SSOP side and male on DIP side enables secure interfacing. Tin over nickel plating on brass contacts guarantees performance and durability.
FR4 housing provides mechanical strengthening and electrical insulation. Through hole mount type with straight orientation fits standard PCB designs. No specific certifications; suited for prototype and industrial electronic adaptation.
Adaptics series allows cost and design efficiency by avoiding redesigns for alternative packages.
Suitable for use in electronics manufacturing, PCB design, prototyping, repair services, and educational labs. Browse the Electronics & Electricals category for further connectors and IC Socket Adapter solutions at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this IC socket adapter is 2.54 mm.
The adapter supports 36 contacts on both the SSOP and DIP sides, ensuring full pin mapping.
The contacts are made of brass and are plated with tin over nickel to ensure reliable conductivity and corrosion resistance.
The housing material is FR4, which provides mechanical strength and electrical insulation during PCB assembly.
The connection gender is female on the SSOP side and male on the DIP side, allowing for secure interfacing between the two formats.
It uses a through hole mounting type with a straight orientation, suitable for standard PCB designs.
This adapter is manufactured in the United Kingdom.
No specific certifications or approvals are applicable to this adapter, indicating it is primarily for engineering and development use cases.
The orientation of the Winslow W9588RC is straight, which aids in its installation on PCB layouts.
This model can adapt between SOP, SSOP, TSOP, TSSOP, MSOP, and QSOP packages to DIP layouts.
Its primary use case is to facilitate the adaptation of integrated circuit packages for compatibility in electronic circuit boards, particularly in prototyping and development environments.
