Murata Power Solutions 6.8 mH Leaded Inductor Radial Mount, Max DC Current 500 mA, Max SRF 500 kHz, Q 50, 2810 mΩ 1468505C

Murata Power Solutions 1468505C is a 6.8 mH leaded inductor from the 1400 series offering radial mounting suitable for high current power line applications such as switching regulators, filters, and suppression circuits. This inductor features a high saturation flux density core, making it ideal for demanding environments. Rated for a maximum DC current of 500 mA, it ensures efficient performance with a maximum DC resistance of 2810 mΩ and a quality factor of 50.

The component utilizes easy-strip pre-tinned enamelled copper leads with a lead diameter of 0.39 mm and a lead pitch of 23 mm, facilitating reliable solder termination on PCBs or chassis. Its dimensions include a diameter of 24.4 mm, height of 15.5 mm, length of 26.7 mm, and depth of 25.9 mm, enabling compact integration into electronic assemblies.

Operating across a wide temperature range from -40°C to 85°C, the inductor maintains an inductance tolerance of ±10%, making it suitable for stable filtering and power applications. It complies with RoHS standards, ensuring environmental safety, and is manufactured in China.

This inductor’s maximum self-resonant frequency is 500 kHz, supporting efficient operation within this frequency limit. The design includes a central fixing hole to allow mounting with a non-magnetic fastener, providing versatility for both PCB and chassis installations.

Murata Power Solutions is a recognized leader in passive electronic components, and the 1400 series reflects high-quality manufacturing suited for industrial, electronic, and power management use cases.

Constructed from high saturation flux density material supporting high current use. Radial mounting style with easy-strip, pre-tinned leads for straightforward PCB integration. Wide operating temperature range suitable for varied environmental conditions.

RoHS compliant for environmental and health safety standards. Compact form factor facilitating space-efficient design. Reliable solder termination with 23 mm lead pitch for mounting stability. Maximum self-resonant frequency of 500 kHz enhances signal integrity.

Quality factor of 50 guarantees efficient inductive performance. Explore more inductors and components in the Electronics category at EnvMart to meet your industrial or laboratory requirements.
