Murata Power Solutions 6.8 mH Ferrite Bobbin Radial Inductor 700 mA Max DC Current 0.4 MHz Max SRF 1400 Series 1468507C

Murata Power Solutions 1468507C is a high current radial ferrite bobbin inductor offering 6.8 mH inductance. It is specifically designed for power line applications including switching regulators, filters, and suppression circuits requiring stable inductance and high current handling.

The ferrite bobbin core provides high saturation flux density, making it suitable for demanding electrical environments. This radial mount inductor features a solder termination style, with pre-tinned enamelled copper leads that are easy to strip for efficient installation.

With a maximum DC current rating of 700 mA and maximum DC resistance of 2.3 Ω, this inductor ensures reliable electrical performance. Its dimensions - 24.4 mm diameter, 25.9 mm length, 18.5 mm height, and 23 mm lead pitch - offer versatility for PCB or chassis mounting using a non-magnetic fastener through the central fixing hole.

The 1400 Series inductors maintain an inductance tolerance of ±10% and a minimum quality factor of 47. They operate across a wide temperature range from -40 to +85 °C, ensuring stability in various industrial environments.

The maximum self-resonant frequency is 0.4 MHz, ideal for filtering and suppression in high frequency circuits. This product is RoHS compliant, confirming adherence to environmental regulations.

Common applications include power supplies, industrial electronics, and other electrical systems requiring robust inductors with consistent characteristics over temperature and current ranges. The sturdy ferrite bobbin construction ensures durability and performance consistency.

Overall, the Murata Power Solutions 1468507C inductor is a reliable component for industrial, laboratory, electronic manufacturing, and commercial electrical uses, supporting rigorous operational demands.

Explore comprehensive electronic component selections and solutions at EnvMart for industrial and professional applications. Operates with a maximum DC current of 700 mA for robust performance. Ferrite bobbin core material ensures high saturation flux density.

Maximum self-resonant frequency of 0.4 MHz supports effective filtering. Constructed for radial mounting with solder termination and 0.43 mm lead diameter. Compact dimensions with 24.4 mm diameter, 25.9 mm length, and 18.5 mm height for PCB or chassis mounting.

Inductance tolerance of ±10% and minimum quality factor of 47 ensure precise electrical characteristics. Designed to operate reliably between -40°C and +85°C temperature range. Lead pitch of 23 mm and easy-strip pre-tinned enamelled copper leads facilitate installation.

Complies with RoHS standards for environmental safety. Part of the 1400 Series offering high current radial inductors suitable for power line applications.
