TE Connectivity Coaxial Connector Panel Mount Female SHV, Straight Body, Solder Termination 51494-2
Specifications
| Country of Origin | India |
|---|---|
| Size | Standard |
| Brand | TE Connectivity |
| Orientation | Straight |
| Model | 51494-2 |
| Mount Type | Panel Mount |
| Operating Frequency | 0.3GHz |
| Contact Material | Beryllium Copper Alloy |
| Termination Type | Solder |
| Maximum Operating Temperature | 165°C |
| Minimum Operating Temperature | -65°C |
| Polarity | Normal |
| Contact Plating | Gold |
| Contact Gender | Male |
| Connector Gender | Female |
| Coaxial Connector Type | SHV |
| Body Plating | Nickel |
Key Features
- Panel mount type with nickel plated body for durability and corrosion resistance.
- Straight orientation with a female SHV connector and male contact.
- Operates up to 0.3 GHz frequency suitable for RF applications.
- Temperature range from -65°C minimum to 165°C maximum for robust environmental performance.
- Gold-plated contact with beryllium copper alloy for reliable conductivity and corrosion resistance.
- Solder termination type provides secure cable connections.
- Polarized normal polarity ensures correct mating and prevents misconnection.
- Designed with a bulkhead mounting and supplied with jam nut and lockwasher for panel fixation.
Product Description
TE Connectivity 51494-2 is a Coaxial Connector designed as a panel mount female SHV with a straight body and solder termination. This connector assembly features a durable nickel-plated body for enhanced corrosion resistance and a gold-plated beryllium copper alloy contact to optimize electrical conductivity and reliability. The connector supports operation at frequencies up to 0.3 GHz and functions reliably in temperature ranges from -65°C to 165°C, making it suitable for demanding industrial and electronic applications.
The 51494-2 connector offers a bulkhead mounting configuration secured with a jam nut and lockwasher, ensuring a robust mechanical connection to panels or enclosures. Featuring polarized normal polarity and a bayonet-locking coupling, it avoids mismating and provides secure, shielded disconnects for high-voltage connections up to 5,000 volts DC. The solder termination enables stable cable attachment, commonly used with small coaxial cables in RF systems.
Applications for this connector include industrial instrumentation, electronic testing equipment, communication devices, and other high-voltage RF applications requiring reliable panel-mounted coaxial connections. Its rugged design and robust operational parameters ensure long-term performance in harsh environments.
Panel mount with nickel plating for mechanical strength and resistance. Straight orientation with female SHV connector and male contacts. Gold-plated beryllium copper contacts for excellent electrical properties. Solder termination for reliable cable connection.
Polarized to prevent incorrect mating. Supports operating frequency up to 0.3 GHz. Operating temperature range from -65°C to 165°C. Bayonet-locking coupling for secure and shielded connection. Bulkhead mounting with jam nut and lockwasher included.
Explore more connectors and electronic components within the EnvMart platform for your industrial and laboratory applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating frequency of this connector is 0.3 GHz, making it suitable for RF applications.
This model operates within a temperature range from -65°C to 165°C, allowing it to perform reliably in harsh environments.
It features a solder termination type, which provides a secure connection for cable attachments.
The contacts are made from a beryllium copper alloy and are gold-plated to optimize electrical conductivity and corrosion resistance.
This connector is designed for panel mount installation and is supplied with a jam nut and lockwasher for secure fixation.
The connector gender is female, while the contact gender is male, ensuring proper mating and connection.
Yes, it has polarized normal polarity to prevent incorrect mating during installation.
The body of this connector is nickel-plated, which enhances its mechanical strength and corrosion resistance.
This connector is suitable for industrial instrumentation, electronic testing equipment, communication devices, and high-voltage RF applications.
It features a bayonet-locking coupling that provides a secure and shielded connection for high-voltage applications up to 5,000 volts DC.
The connector is classified as a standard size, making it compatible with various applications and installations.
The country of origin for this connector is India.
