DiodesZetex 3.3 V Zener Diode Common Cathode 300 mW Surface Mount SOT-23 3-Pin DZ23C3V3-7-F

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex 3.3 V Zener Diode Common Cathode 300 mW Surface Mount SOT-23 3-Pin DZ23C3V3-7-F

Name: DiodesZetex 3.3 V Zener Diode Common Cathode 300 mW Surface Mount SOT-23 3-Pin DZ23C3V3-7-F
Brand: DiodesZetex
SKU: 217438
Price: 0.08 USD
Availability: InStock



Category Zener Diode Brand DiodesZetex Condition New

Specifications

Country of Origin	China
Brand	DiodesZetex
Height	1.1mm
Length	3mm
Model	DZ23C3V3-7-F
Mount Type	Surface
Series	DZ23C
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Number of Elements per Chip	2
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	300mW
Diode Configuration	Common Cathode
Test Current It	5mA
Maximum Reverse Leakage Current	100nA
Nominal Zener Voltage Vz	3.3V
Zener Type	Voltage Regulator
Maximum Zener Impedance	500Ω

Key Features

This diode features a common cathode configuration suitable for surface mounting.
It comes in a compact SOT-23 3-pin package for efficient PCB layouts.
The device operates reliably from -65°C to 150°C with tight Zener voltage tolerance of ±5%.
Maximum reverse leakage current is extremely low at 100 nA, ensuring high performance.
Tested at 5 mA test current with maximum Zener impedance of 500 Ω.
Complies with automotive standard AEC-Q101 for quality assurance.

Product Description

DiodesZetex DZ23C3V3-7-F is a 3.3 V Zener diode designed for voltage regulation and stabilization in electronic circuits. Featuring a common cathode 3-pin configuration and housed in a surface mount SOT-23 package, this device offers efficient integration into compact PCB assemblies.

The diode supports a maximum power dissipation of 300 mW, making it suited for low-power voltage regulation applications across industrial and automotive sectors. Its operating temperature range from -65°C to 150°C ensures reliable performance in harsh environments.

With a nominal Zener voltage of 3.3 V and a tolerance of ±5%, the DZ23C3V3-7-F provides precise voltage regulation. The device is tested at 5 mA current and features a maximum Zener impedance of 500 Ω and a minimal reverse leakage current of 100 nA, enabling efficient voltage clamping with low losses.

The diode meets automotive standard AEC-Q101, ensuring quality and robustness required in demanding automotive applications. Its compact dimensions of 1.1 mm height and 3 mm length facilitate integration into dense electronic circuits.

This diode is ideal for use in industrial electronics, automotive electronic systems, power supplies, and other voltage regulation needs. The common cathode design simplifies circuit layouts where multiple diodes are used.

Its surface mount SOT-23 package suits automated manufacturing and space-constrained applications. Set your designs with reliable voltage regulation using DiodesZetex DZ23C3V3-7-F. Browse more Zener Diodes and related semiconductor components on EnvMart for tailored solutions.
