DiodesZetex 3.3 V Zener Diode Common Cathode 300 mW 5% Surface Mount 3-Pin SOT-23 DZ23C3V3-7-F

DiodesZetex DZ23C3V3-7-F is a 3.3 V Zener Diode featuring a common cathode configuration designed for surface mount technology applications. It offers voltage regulation capabilities with a maximum power dissipation of 300 mW, making it suitable for precise voltage stabilization in electronic circuits.

This Zener Diode is part of the DZ23C series and features two elements per chip for enhanced performance. Packaged in a small 3-pin SOT-23 surface mount package, it is ideal for high-density PCB layouts in industrial, automotive, and electronic manufacturing applications.

Key operational parameters include a maximum operating temperature of 150°C and a broad temperature range from -65°C which supports reliability in harsh environments. The device operates at a test current of 5 mA and demonstrates a low maximum reverse leakage current of 100 nA and a maximum Zener impedance of 500 Ω, ensuring low noise and stable voltage regulation.

The diode meets the AEC-Q101 standard for automotive applications, ensuring robustness and endurance required for automotive systems and other demanding uses.

Typical applications include voltage regulation in power supply circuits, overvoltage protection, and reference voltage generation in industrial machinery, consumer electronics, and automotive electronic control units.

The diode features a nominal Zener voltage of 3.3 V with ±5% tolerance providing precise voltage regulation. Two elements per chip in a common cathode configuration enable improved current sharing and reliability. Compact 3-pin SOT-23 package supports high-density surface mount PCB design.

300 mW power dissipation supports moderate power applications with temperature ratings from -65°C to 150°C. Maximum reverse leakage current of 100 nA and Zener impedance of 500 Ω minimize leakage and maintain stability. Compliance with AEC-Q101 automotive standards for quality and durability.

DiodesZetex offers this high-quality Zener diode as a reliable component for semiconductor applications requiring controlled voltage reference and protection. It is engineered to maintain performance over wide environmental and thermal conditions, making it essential for electronic, automotive, and industrial circuits. Browse more Zener Diode options and related semiconductor components on EnvMart for your industrial and manufacturing needs.
