3M Textool 2.54 mm Pitch Vertical 48 Way Through Hole Closed Frame ZIF IC Dip Socket 248-1282-00-0602J

Free Delivery in India | Lowest Global Shipping Charges

3M Textool 2.54 mm Pitch Vertical 48 Way Through Hole Closed Frame ZIF IC Dip Socket 248-1282-00-0602J



Category IC Socket Brand 3M Condition New

Specifications

Country of Origin	Japan
Voltage	500V
Brand	3M
Orientation	Vertical
Current	1A
Frame Type	Closed Frame
Length	88.1mm
Model	248-1282-00-0602J
Depth	22.9mm
Width	11.9mm
Mount Type	Through Hole
Housing Material	Polysulfone
Contact Material	Beryllium Copper Alloy
Series	Textool
Durability	20000 actuations (at 24°C)
Termination Type	Solder
Maximum Operating Temperature	150°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Standards/Approvals	UL, RoHS
Contact Plating	Gold over Nickel
Number of Contacts	48
Row Width	15.24mm

Key Features

Supports dual in-line packages with vertical, closed frame design for mechanical strength.
Features a lever-actuated zero insertion force mechanism for easy insertion and removal.
Constructed with beryllium copper alloy contacts and gold over nickel plating for high conductivity and corrosion resistance.
Durable for 20,000 actuations at room temperature with operation from -55°C to 150°C.
Ideal for high-volume hand-testing, programming, factory automation, and laboratory use.
Compact dimensions of 88.1 mm length, 22.9 mm depth, and 11.9 mm width optimize PCB space.
Complies with UL and RoHS standards ensuring quality and environmental safety.

Product Description

3M 248-1282-00-0602J Textool 48 Way Vertical ZIF IC Dip Socket is a precision-engineered electrical component designed to facilitate high-reliability connections for dual in-line packages (DIP) with a 2.54 mm pin pitch. This socket features a vertically oriented, through-hole mounting style combined with a closed frame structure, providing enhanced mechanical strength and stability on printed circuit boards (PCBs).

The device incorporates a lever-actuated zero insertion force (ZIF) mechanism, allowing easy insertion and removal of ICs without damaging the component leads or cables. Constructed with beryllium copper alloy contacts, which are gold plated over nickel, this socket ensures excellent electrical conductivity and resistance to corrosion and oxidation. This makes it suitable for demanding industrial and laboratory environments.

Rated for 1 ampere current and 500 volts operating voltage, it supports reliable electrical performance. The socket tolerates a wide temperature range from -55°C to 150°C, suitable for diverse testing and operational conditions. It is rated for up to 20,000 insertion/removal cycles at room temperature, assuring long service life.

The compact physical dimensions of 88.1 mm length, 22.9 mm depth, and 11.9 mm width enable efficient PCB utilization. The polysulfone housing material provides electrical insulation and durability. Compliant with UL and RoHS standards, this product meets rigorous safety and environmental regulations.

Applications include factory automation, electronics manufacturing, high-volume hand testing, programming, and laboratory testing where quick modifications and reliable electrical contacts are critical.

Supports 48-contact DIP ICs with 2.54 mm pitch. Through-hole vertical mounting for robust PCB attachment. Gold-over-nickel plated beryllium copper contacts for longevity and conductivity. Lever-actuated zero insertion force design minimizes IC lead damage.

Operation temperature range from -55°C to 150°C with UL and RoHS compliance. Durability for 20,000 cycles at 24°C for high-volume usage. Polysulfone housing offers insulation and mechanical strength. Explore the comprehensive range of 3M electronic components and connectivity solutions at EnvMart for reliable industrial and laboratory applications.

Explore more products in our IC Socket category.
