3M 10-Way IDC Connector Female for Cable, 2 Row, 125 V AC, 2.5 A Current, Gold over Nickel Plating 45110-010030

Free Delivery in India | Lowest Global Shipping Charges

3M 10-Way IDC Connector Female for Cable, 2 Row, 125 V AC, 2.5 A Current, Gold over Nickel Plating 45110-010030



Category IDC Connectors Brand 3M Condition New

Specifications

Country of Origin	United States
Voltage	125V ac
Brand	3M
Orientation	Straight
Operating Temperature	-65 to +105 °C
Current	2.5A
Mount Type	Cable
Housing Material	Polybutylene Terephthalate
Contact Material	Beryllium Copper
Current Rating	1.0 A (all lines energized), 1.5 A (6 lines energized), 2.5 A (1 line energized)
Series	451
Termination Type	Crimp
Maximum Operating Temperature	105°C
Voltage Rating	125 V min
Minimum Operating Temperature	-65°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold over Nickel
Number of Contacts	10
Contact Gender	Female
Connector Gender	Female
Shrouded/Unshrouded	Shrouded
Processing temperature	260 °C
HARWIN 10-Way IDC Connector Female for Cable, 2 RowBrand	HARWIN

Key Features

Features a shrouded, straight orientation female connector with 2 rows and 10 contacts.
Contact plating is gold over nickel for enhanced conductivity and corrosion resistance.
Constructed from beryllium copper contacts and polybutylene terephthalate housing for durability.
Operates reliably between -65°C and 105°C, with a processing temperature up to 260°C.
Termination is via crimp type, suitable for cable mount with 1.27 mm pitch.
Lead-free solderable, compliant with environmental standards.
Designed to mate with the 452 series board mount headers.
Ideal for electronics, power connectors, and PCB wiring applications.

Product Description

3M 45110-010030 10-Way IDC Connector Female for Cable, 2 Row, rated for 125 V AC and 2.5 A maximum current, is a high-density ribbon cable socket assembly engineered for demanding electronics and industrial use cases. Featuring fine 1.27 mm pitch spacing and shrouded design, it ensures a secure connection with minimal size footprint.

The connector houses ten female contacts arranged in two rows. The gold over nickel plating facilitates excellent electrical conductivity and protection against corrosion. Contacts are made of high-conductivity beryllium copper, while the housing uses durable polybutylene terephthalate (PBT), offering robust mechanical and thermal performance.

Operating temperature ranges from -65°C to +105°C with the capability to process at 260°C, making it suitable for soldering and assembly processes. Termination is crimp type, ensuring reliable cable attachment with strain relief compatibility.

This connector is compatible with 452 series board mount headers and is lead-free solderable, adhering to modern RoHS compliant manufacturing standards. It is widely used across electronic components manufacturing, power connection systems, and PCB assemblies, especially in industrial, commercial, and laboratory environments.

Shrouded, straight female connector with 10 contacts in two rows. High-density 1.27 mm pitch suitable for fine pitch applications. Gold over nickel plating enhances conductivity and corrosion resistance. Durable materials: beryllium copper contacts and PBT housing.

Operating temperature -65°C to 105°C, processing up to 260°C. Crimp termination type designed for cable mounting and strain relief. Lead-free solderable complying with RoHS environmental standards. Manufactured in the United States ensuring high quality.
