Samtec QSH Series Straight Surface PCB Socket 60-Contact 2 Row 0.5 mm Pitch 25A 175V QSH-030-01-F-D-A-K

Free Delivery in India | Lowest Global Shipping Charges

Samtec QSH Series Straight Surface PCB Socket 60-Contact 2 Row 0.5 mm Pitch 25A 175V QSH-030-01-F-D-A-K

Name: Samtec QSH Series Straight Surface PCB Socket 60-Contact 2 Row 0.5 mm Pitch 25A 175V QSH-030-01-F-D-A-K
Brand: Samtec
SKU: 215915
Price: 6.07 USD
Availability: InStock



Category PCB Sockets Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	175V
Brand	Samtec
Orientation	Straight
Current	25A
Model	QSH-030-01-F-D-A-K
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Bronze
Series	QSH
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Board-to-Board
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	0.5mm
Contact Plating	Gold
Number of Contacts	60
Connector System	Board-to-Board
Stacking Height	5mm

Key Features

This PCB socket has a 5 mm stacking height for low-profile applications.
Constructed with liquid crystal polymer housing for durability and thermal stability.
Contacts are made of bronze with gold plating to ensure reliable conductivity and corrosion resistance.
Suitable for high-speed differential pair signaling up to 9.5 GHz / 19 Gbps.
Operates in a temperature range from -55°C to 125°C for versatile industrial environments.
Surface mount termination by soldering for secure mechanical and electrical connection.
Designed for board-to-board connector systems with a straight orientation and 0.5 mm pitch.
Supports continuous current rating of 25A and voltage rating of 175V.

Product Description

Samtec QSH-030-01-F-D-A-K is a high-performance PCB socket designed to provide reliable connections in electronic assemblies requiring compact board-to-board interfaces. The straight surface mount board-to-board connector features 60 contacts arranged in 2 rows with a 0.5 mm pitch, accommodating high-density layouts and low-profile designs with its 5 mm stacking height.

This socket utilizes a liquid crystal polymer housing that offers excellent mechanical strength and resistance to high temperatures, ensuring consistent performance in demanding industrial and electronics manufacturing environments.

The contacts are fabricated from bronze and plated with gold, enhancing conductivity and preventing corrosion, which is essential for high reliability in automotive, aerospace, telecommunications, and computing applications.

Supporting a current rating of 25A and voltage up to 175V, this PCB socket is engineered to handle robust electrical loads while maintaining signal integrity. It is optimized for high-speed data transmission up to 9.5 GHz or 19 Gbps using differential pair technology, suitable for modern high-frequency electronic devices.

The operating temperature range of -55°C to 125°C makes it versatile for various industrial, commercial, and laboratory applications, including embedded systems and PCB assembly lines in harsh environmental conditions.

This PCB socket features a solder termination style to ensure a strong, permanent connection to the board. The straight orientation and surface mount capability simplify PCB layout and assembly processes. Its compliance with essential industry requirements, despite no specific standards or approvals listed, makes it ideal for general-purpose electronic component integration.

Set contains one Samtec QSH Series PCB Socket with 60 contacts and 2 rows, model number QSH-030-01-F-D-A-K. Explore EnvMart for more high-quality electronic components, connectors, sockets, and PCB accessories by Samtec for your professional industrial and laboratory needs.
