Winslow Straight Through Hole Mount 7.62 mm Pitch IC Socket Adapter DIP to DIP W9117RC

Free Delivery in India | Lowest Global Shipping Charges

Winslow Straight Through Hole Mount 7.62 mm Pitch IC Socket Adapter DIP to DIP W9117RC

Name: Winslow Straight Through Hole Mount 7.62 mm Pitch IC Socket Adapter DIP to DIP W9117RC
Brand: Winslow
SKU: 215848



Category IC Socket Adapter Brand Winslow Condition New

Specifications

Country of Origin	United Kingdom
Brand	Winslow
Orientation	Straight
Model	W9117RC
Mount Type	Through Hole
Housing Material	FR4
Contact Material	Brass
Pitch	7.62mm
Contact Plating	Gold over Nickel
Connection Gender A	Female
Number of Contacts A	28
Connection Gender B	Male
PCB	Epoxy Fibreglass FR4
Connection A	DIP

Key Features

This IC socket adapter features 28 female contacts on connection A.
It has 28 male contacts on connection B.
Contacts are plated with gold over nickel for reliable conductivity and corrosion resistance.
The contact material is brass, and housing material is high-quality FR4 epoxy fiberglass.
This adapter allows conversion between dual in line package pitches, reducing PCB redesign costs.
The PCB material is epoxy fiberglass FR4 for durability and stability.
Mount type is through hole, providing secure and stable PCB mounting.

Product Description

Winslow W9117RC is a premium IC Socket Adapter designed for straight orientation through hole mount applications, featuring a 7.62 mm pitch. It facilitates conversion between dual in line package (DIP) pitches, enabling easy adaptation of IC packages without the need for costly PCB redesigns. This device is ideal for industrial, electronics manufacturing, research and development, and prototyping environments.

The adapter includes 28 female contacts on side A and 28 male contacts on side B, ensuring a robust electrical connection for various DIP components. Contacts are plated with gold over nickel, enhancing conductivity and corrosion resistance. The contact material is brass, chosen for durability and reliable electrical performance.

The housing is constructed of FR4 epoxy fiberglass, providing mechanical strength and stability under operating conditions. This material choice ensures long-lasting performance and resistance to environmental factors.

Mounting is by through hole technique, securing the component firmly onto the printed circuit board. The adapter is perfectly suited for applications that require conversion of IC packages, reducing development time and costs.

This IC socket adapter features 28 female contacts on connection A. It has 28 male contacts on connection B. Contacts are plated with gold over nickel for reliable conductivity and corrosion resistance. The contact material is brass, and housing material is high-quality FR4 epoxy fiberglass.

The PCB base is epoxy fiberglass FR4 for enhanced durability. Mount type is through hole with straight orientation for ease of installation.

This component is manufactured in the United Kingdom and conforms to industrial standards. It is a reliable choice for electronics engineers, technicians, and designers involved in PCB assembly, testing, and prototyping.
