Preci-Dip 813 Series Straight Surface Spring Loaded Connector, 10 Contacts, 2.54 mm Pitch, 2 Row 813-S1-010-30-016191

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 813 Series Straight Surface Spring Loaded Connector, 10 Contacts, 2.54 mm Pitch, 2 Row 813-S1-010-30-016191

Name: Preci-Dip 813 Series Straight Surface Spring Loaded Connector, 10 Contacts, 2.54 mm Pitch, 2 Row 813-S1-010-30-016191
Brand: Preci-Dip
SKU: 215569
Price: 13.1 USD
Availability: InStock



Category PCB Connectors Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Straight
Current	3.5A
Model	813-S1-010-30-016191
Mount Type	Surface
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass
Series	813
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	10
Contact Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

The connector features 2.54 mm pitch and is shrouded for protection.
Housing material is fibreglass reinforced polyethylene terephthalate for durability.
Contacts are brass with gold plating for reliable electrical conductivity.
Designed for surface mount pad mounting with straight orientation.
Operates reliably from -55°C up to 125°C.
Rated for 3.5 A current and 150 V voltage.
Includes 10 male contacts with a 2 row configuration.
The spring-loaded contacts ensure low resistance and stable electrical connections under vibration or movement.

Product Description

Preci-Dip 813-S1-010-30-016191 is a high-quality straight surface mount spring loaded connector designed for electronic PCB applications. This connector features 10 brass contacts plated with gold, arranged in 2 rows with a 2.54 mm pitch, providing reliable and stable electrical connections.

The connector housing is constructed from fibreglass reinforced polyethylene terephthalate, offering excellent durability and thermal stability. It is shrouded for additional protection and designed for surface mount pad mounting with straight orientation. The spring-loaded contacts provide low resistance and maintain connectivity even under vibration or movement, ensuring consistent performance in demanding industrial, laboratory, and manufacturing environments.

The operating temperature range of -55°C to 125°C makes this connector suitable for a wide variety of applications, including power connectors and PCB headers in electronics and electrical systems. Rated for up to 3.5 A current and 150 V voltage, it meets the practical requirements for medium power electronic circuits.

This product is manufactured in Switzerland and represents a robust alternative to conventional connection methods by providing multipoint contact between the mobile piston and clip, which eliminates micro-discontinuities and maximizes reliability.

The connector includes 10 spring-loaded contacts arranged in 2 rows for compact design. Gold-plated brass contacts ensure excellent corrosion resistance and conductivity. Fibreglass reinforced plastic body offers strong mechanical and thermal properties.

Shrouded design improves connector safety and handling. Surface mount straight orientation facilitates easy PCB assembly. Wide operating temperature range from -55°C to 125°C supports harsh working environments. Rated for 3.5 A current and 150 V voltage applications.

Ideal for industrial electronics, power connectors, manufacturing, and laboratory use. Reliable spring-contact technology ensures stable connections despite vibrations or movement. Explore similar PCB Connectors and spring loaded connectors at EnvMart to meet various electronic assembly and repair needs.
