Preci-Dip 811 Series Straight Surface Spring Loaded Connector, 3 Contacts, 2.54 mm Pitch, 1 Row 811-SS-003-30-008191

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 811 Series Straight Surface Spring Loaded Connector, 3 Contacts, 2.54 mm Pitch, 1 Row 811-SS-003-30-008191

Name: Preci-Dip 811 Series Straight Surface Spring Loaded Connector, 3 Contacts, 2.54 mm Pitch, 1 Row 811-SS-003-30-008191
Brand: Preci-Dip
SKU: 215564
Price: 5.18 USD
Availability: InStock



Category PCB Connectors Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Straight
Current	3.5A
Model	811-SS-003-30-008191
Mount Type	Surface
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass
Series	811
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	3
Contact Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

The connector has a shrouded design for enhanced protection.
Contacts are brass with gold plating ensuring reliable electrical connection.
Operates within a temperature range from -55°C to 125°C for versatile use.
Supports a current rating of 3.5 Amperes with a voltage rating of 150V.
The housing is made from fibreglass reinforced polyethylene terephthalate for durability.
Termination type is solder, and contact gender is male.
The connector is suitable for PCB applications requiring low resistance and stable connections.
Manufactured to precise standards ensuring reliability in electronic and industrial uses.

Product Description

Preci-Dip 811-SS-003-30-008191 is a straight surface mount spring loaded connector designed for PCB applications. It features 3 gold-plated brass contacts with a pitch of 2.54 mm arranged in a single row and protected by a shrouded housing made of fibreglass reinforced polyethylene terephthalate.

This connector supports a current capacity of 3.5 Amperes and a voltage rating up to 150V, making it suitable for various electronic component interconnections that require secure and low resistance contacts.

Operating continuously at temperatures ranging from -55°C to 125°C, it achieves reliable performance in harsh environmental conditions found in industrial and electronic manufacturing sectors.

The spring loaded contact mechanism ensures consistent electrical contact with minimal micro-discontinuities even under vibration or movement, enhancing the overall stability and reliability of connections on printed circuit boards.

The connector comes with solderable terminations and male contact gender for ease of installation. Its shrouded design provides additional mechanical protection and alignment aid. The robust housing material offers excellent durability and resistance to mechanical and thermal stresses.

Applications include industrial electronics assembly, testing equipment, embedded system connections, and other demanding environments in commerce and manufacturing industries. Originating from Switzerland, this Preci-Dip connector conforms to UL 94V-0 standards, assuring quality and safety in electrical components.
