Preci-Dip 110 2.54 mm Pitch Vertical 42 Way Through Hole Turned Pin Open Frame DIL Socket 1A 110-87-642-41-001101

Preci-Dip 110-87-642-41-001101 is a high-quality 42-way Dual In-Line (DIL) socket designed with a 2.54 mm pitch for reliable vertical, through hole mounting on printed circuit boards (PCBs). Engineered for use in industrial electronics and automation, it provides a robust and precise interface for ICs and connectors requiring stable electrical contact and mechanical durability.

The socket’s open frame design and turned pin contacts, made from a brass and beryllium copper alloy with tin and gold plating, ensure excellent conductivity and corrosion resistance, ideal for demanding operating environments. The housing fabricated from fibreglass reinforced polyethylene terephthalate offers mechanical strength and resistance to high temperatures.

Rated for a current of 1A and voltages up to 150V AC, this socket supports a broad range of electronic circuits while maintaining safety and performance. It operates reliably within a temperature range of -55°C to 125°C, suitable for environments with varying thermal conditions.

The compact size with a row width of 15.24 mm, length 53.3 mm, width 17.7 mm, and depth 2.8 mm allows efficient PCB layout utilization. The solder termination type and vertical orientation facilitate strong and straightforward assembly in manufacturing processes.

This product complies with UL 94V-0 standards ensuring flame retardance, making it suitable for use in industrial, laboratory, commercial electronics, and manufacturing assembly lines. It provides reliable connectivity for complex electronic assemblies and test circuits.

This DIL socket features 42 contacts with a 2.54 mm pitch for standard PCB compatibility. Manufactured with brass and beryllium copper alloy contacts plated with tin and gold for reliable conductivity. Housing is made from fibreglass reinforced polyethylene terephthalate providing mechanical stability.

Operates within a temperature range of -55°C to 125°C, suitable for harsh environments. Designed for solder termination with an open frame vertical orientation facilitating easy PCB mounting. Supports voltages up to 150V AC, ideal for low-current PCB connections.

Dimensions include a row width of 15.24 mm, length of 53.3 mm, width of 17.7 mm, and depth of 2.8 mm ensuring compact footprint. Constructed to meet UL 94V-0 flame retardant standards enhancing safety. Compatible with various PCB designs requiring dual in-line 2.54 mm pitch socket solutions.
