Samtec TSM Series Straight Surface Pin Header 16 Contacts 2.54 mm Pitch 2 Row Unshrouded TSM-108-02-S-DV

Free Delivery in India | Lowest Global Shipping Charges

Samtec TSM Series Straight Surface Pin Header 16 Contacts 2.54 mm Pitch 2 Row Unshrouded TSM-108-02-S-DV

Name: Samtec TSM Series Straight Surface Pin Header 16 Contacts 2.54 mm Pitch 2 Row Unshrouded TSM-108-02-S-DV
Brand: Samtec
SKU: 215415
Price: 3.29 USD
Availability: InStock



Category PCB Pin Header Brand Samtec Condition New

Specifications

Country of Origin	United States
Voltage	475V
Brand	Samtec
Orientation	Straight
Current	4A
Model	TSM-108-02-S-DV
Mount Type	Surface
Special Features	Designed specifically for surface mount applications with many options to facilitate processing
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	TSM
Termination	Surface mount, mixed technology
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	16
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board, Wire-to-Board
Contact System	.025" (0.635 mm) square post

Key Features

Features 16 male contacts arranged in 2 rows for efficient connectivity.
Pitch of 2.54 mm (0.1 inches) enables precise placement and compatibility.
Constructed with Liquid Crystal Polymer housing for durability.
Phosphor bronze contact material plated with gold ensures reliable conductivity.
Designed as unshrouded type, ideal for easy access during soldering.
Supports a current rating of 4 A and voltage rating up to 475 V.
Surface mount termination type suitable for PCB assembly processes.
Operates reliably between -55°C and 125°C temperature range.

Product Description

Samtec TSM-108-02-S-DV Straight Surface Pin Header is a premium connector designed for electronic and industrial applications requiring high reliability and precision. Featuring 16 gold-plated phosphor bronze contacts arranged in 2 rows with a 2.54 mm pitch, it supports both board-to-board and wire-to-board connector systems.

The housing is made of high-performance Liquid Crystal Polymer, providing excellent mechanical strength and stability under a wide temperature range from -55°C to 125°C. The unshrouded straight orientation allows versatile mounting and easy access for soldering on surface mount PCB assemblies.

This connector is rated for a current of 4 A and a voltage of 475 V, making it suitable for moderate power electronic circuits. The contacts use a .025" (0.635 mm) square post system, which ensures secure and reliable electrical connections.

TSM Series connectors are recognized as Extended Life Products™, capable of withstanding high mating cycles from 250 to 2,500 and passing rigorous 10-year Mixed Flowing Gas (MFG) tests for enhanced longevity in harsh environments.

16 male contacts in a dual-row layout optimize connectivity in compact spaces. Gold plating on contacts ensures excellent corrosion resistance and electrical conductivity. Surface mount termination supports standard PCB manufacturing processes.

Operating temperature range from -55°C to 125°C suits industrial, laboratory, and commercial electronic systems. Limestone Crystal Polymer housing delivers mechanical robustness and thermal stability. Applications include industrial electronics, telecommunications, machinery controls, and other PCB-connected systems.

Country of origin: United States. This product offers reliable interconnect solutions for a wide range of electronics manufacturing and prototyping sectors. Explore more PCB Pin Headers and connectors in the Electronics & Electricals category on EnvMart.
