Preci-Dip 110 2.54 mm Pitch Vertical 24 Way Surface Turned Pin Open Frame DIL Socket 1A 110-87-624-41-105101

Preci-Dip 110-87-624-41-105101 is a high-quality 24 Way Dual-In-Line (DIL) Socket designed to offer precise and durable connections on printed circuit boards. Featuring a 2.54 mm pitch and vertical surface mount configuration, this open frame socket is ideal for industrial electronic manufacturing and laboratory testing environments. The turned pins and four-finger gold-flashed contact clips provide excellent conductivity and reliable mechanical strength.

Constructed from beryllium copper alloy and brass, the contacts are plated with tin and a gold flash, ensuring resistance to corrosion and wear. The housing is made of fibreglass reinforced polyethylene terephthalate, providing robust insulation compatible with a maximum operating temperature of 125°C and a minimum of -55°C.

Its compact dimensions of 30.5 mm length, 17.7 mm width, and 2.8 mm depth make it suitable for space-constrained designs. The product supports up to 1 Amp current and 150 V DC voltage, fitting a wide range of electronic applications including circuit prototyping, industrial control units, and electronic instrumentation.

The Preci-Dip 110 Series DIL sockets come with open frame design, optimized for in-circuit testing and easy solder reflow processes with gull wing terminations. This product complies with UL 94V-0 standards for flame retardancy, ensuring safety in demanding industrial environments.

Designed for 24 contact points with 2.54 mm pitch for reliable electrical connections. Vertical orientation with surface mount type suitable for reflow soldering applications. Open frame construction for optimal airflow and easy inspection.

Constructed with beryllium copper alloy and brass contacts plated with tin and gold flash. Fibreglass reinforced polyethylene terephthalate housing ensures durability and excellent insulation. Operates reliably between -55°C to 125°C temperature range.

Supports voltage up to 150 V DC for diverse electronic applications. Compact dimensions: Length 30.5 mm, Width 17.7 mm, Depth 2.8 mm. Suitable for industrial, electronic manufacturing, and testing equipment. Originates from Switzerland, ensuring high manufacturing standards.

This Preci-Dip DIL Socket 110-87-624-41-105101 is a crucial component for electronics design, assembly, and repair. Explore more high-quality DIL Sockets and related electronic components on EnvMart for seamless integration in your industrial and laboratory projects.
