Preci-Dip 110 2.54 mm Pitch Vertical 10 Way Surface Turned Pin Open Frame DIL Socket 1A 110-87-310-41-105101

Preci-Dip 110-87-310-41-105101 is a 10 Way surface mount Dual In-Line (DIL) socket with a 2.54 mm pitch, designed for vertical mounting in electronic assemblies. This open frame socket features turned pins and a robust beryllium copper alloy with brass contact construction, combining high mechanical strength and excellent electrical conductivity.

The socket is plated with a combination of gold and tin to provide superior corrosion resistance and consistent contact performance. Designed for solder termination, it accommodates reliable PCB mounting using Gull Wing legs, ideal for reflow soldering processes including vapor phase soldering.

Its vertical orientation and open frame design allow for easy access during circuit testing and assembly, making it suitable for complex electronic manufacturing and repair applications. Rated for a current of 1 ampere and operating voltages of 100 to 150 V AC, the socket offers stable electrical performance under various conditions.

Operating temperature ranges from -55°C to 125°C, enabling usage in harsh environments. Physical dimensions are compact, with measurements of 12.6 mm length, 10.1 mm width, 2.8 mm depth, and a row width of 7.62 mm, ensuring efficient space utilization on printed circuit boards.

The housing is constructed from fibreglass reinforced polyethylene terephthalate, providing electrical insulation and structural durability. The product is part of the Preci-Dip 110 Series and manufactured in Switzerland, known for precision-engineered electronic components.

The socket features 10 contacts with a 2.54 mm pitch for precise IC connections. Constructed with beryllium copper alloy and brass contacts for durability and conductivity. Contact plating combines gold and tin to ensure reliable signal transmission and corrosion resistance.

The open frame design and vertical orientation facilitate easy in-circuit testing and PCB assembly. Rated for 1A current and operates at voltages of 100 to 150 V AC. Suitable for solder termination with surface mount mount type and Gull Wing terminations.

Operating temperature range spans from -55°C to 125°C for versatile environmental conditions. Compact dimensions include length 12.6 mm, width 10.1 mm, depth 2.8 mm, and row width 7.62 mm. The housing is made of fibreglass reinforced polyethylene terephthalate for mechanical strength and insulation.

Manufactured in Switzerland, ensuring high quality standards and reliability.

This Preci-Dip open frame DIL socket is suitable for industrial electronics manufacturing, laboratory setups, manufacturing diagnostics, and prototyping where precision IC sockets are required. It integrates well in commercial PCB assemblies and electronic repair environments.
