Preci-Dip 2.54 mm Pitch Vertical 14 Way Surface Turned Pin Open Frame DIL Socket 1A 110-87-314-41-105101

Preci-Dip 110-87-314-41-105101 is a high-quality 14 way DIL (Dual In-Line) socket designed for surface mounting on printed circuit boards with a 2.54 mm pitch between pins. It features a vertical open frame construction with turned pin contacts plated in gold and tin to ensure excellent electrical conductivity and corrosion resistance.

This socket type enables easy replacement and secure connection for ICs, providing a current rating of 1 ampere suitable for many electronic control and instrumentation applications. The frame is constructed of fibreglass reinforced polyethylene terephthalate which offers mechanical strength and stability.

The contact material combines beryllium copper alloy and brass, delivering reliable performance over a wide operating temperature range from -55°C to 125°C. With a voltage rating up to 150 volts AC, this socket is suitable for various industrial, commercial, and laboratory electronics assembly tasks.

The compact dimensions of 10.1 mm width, 17.7 mm length, and 2.8 mm depth with a row spacing of 7.62 mm allow for efficient PCB layout and multiple socket installations. Manufactured in Switzerland according to the 110 Series standards, these sockets comply with UL 94V_0 flame retardant regulations ensuring safety and quality standards compliance.

This socket is designed for surface mount technology with solder termination type, providing strong mechanical and electrical connection to PCB. Its vertical orientation and open frame design allow for visual inspection of connections and easy in-circuit testing.

Gold and tin plating on contact clips enhances durability and minimizes signal loss. Ideal for industrial electronics, manufacturing automation, telecommunications equipment, and laboratory instrumentation where reliable IC socket connections are essential.

Offers long-term reliability in harsh conditions due to robust material selection and construction standards. This 110 Series open frame DIL socket is an ideal component for engineers and technicians involved in PCB assembly, electronic equipment prototyping, and repair jobs.
