Preci-Dip 14 Way Surface Mount Vertical Turned Pin Open Frame DIL Socket 2.54 mm Pitch 1A 110-87-314-41-105101

Preci-Dip 110-87-314-41-105101 is a highly reliable 14 way Dual-In-Line (DIL) socket designed with a 2.54 mm pitch and vertical orientation for surface mount PCB applications. This open frame DIL Socket supports through hole or surface mount reflow soldering processes including vapour phase, featuring gull wing termination for maximum mechanical strength and ease during in-circuit testing on printed circuit boards.

The socket incorporates sleeves made of tin-plated brass combined with four-finger gold flash contact clips, ensuring excellent conductivity and corrosion resistance. The contacts are manufactured from beryllium copper alloy and brass, while the housing is constructed from fibreglass reinforced polyethylene terephthalate, providing high mechanical stability and thermal resistance suitable for industrial environments.

This product supports an operating current of 1 ampere and voltage ratings of 100 V to 150 V AC. It operates reliably within a wide temperature range from -55°C to 125°C, making it suitable for various industrial, electronic manufacturing, and laboratory applications requiring dependable connection sockets with durability and precision.

The compact size with dimensions 17.7 mm in length, 10.1 mm in width, and 2.8 mm depth allows for dense PCB layouts without compromising accessibility or performance. Designed for precise through hole or surface mount integration on PCBs, supporting vapour phase and reflow solder processes.

Open frame construction improves ease of testing and inspection during manufacturing. High-quality materials including beryllium copper alloy contacts and fiberglass reinforced PET housing ensure durability and performance.

Suitable for electronics manufacturing, industrial automation, and laboratory testing environments. Supports safe operation over a broad temperature range and voltage rating. Compact footprint allows high component density on circuit boards.

Gold and tin plating provide excellent electrical contact and corrosion resistance.

Package supplied in tubes prepared for insertion into machinery to enhance production efficiency. Use Preci-Dip sockets to ensure high reliability connections in complex electronic assemblies.

Explore EnvMart’s wide range of electronic components and connectors for industrial and commercial applications where precision and reliability are essential.
