Nexperia Surface Mount Schottky Diode 30 V 2 A 2-Pin SOD-128 PMEG3020CEP,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 4mm |
| Model | PMEG3020CEP,115 |
| Width | 2.7mm |
| Mount Type | Surface |
| Series | PMEG3020CEP |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-128 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 2A |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1.5mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 420mV |
| Average forward current | IF(AV) ≤ 2 A |
| Reverse voltage | VR ≤ 30 V |
Key Features
- Designed for low forward voltage and high efficiency applications.
- Encapsulated in a small, flat SOD-128 plastic SMD package suitable for automated PCB assembly.
- Provides an average forward current of up to 2 A and a peak surge current of 50 A.
- Rated for operating temperatures from -55°C up to 150°C.
- Offers reverse polarity protection and low power consumption.
- Qualified to AEC-Q101 automotive standards for reliable performance in harsh environments.
- Features clip-bond technology ensuring high power capability and mechanical robustness.
- Ideal for DC-DC conversion, switch mode power supplies (SMPS), and low voltage rectification.
Product Description
Nexperia PMEG3020CEP,115 Schottky diode is a high-performance discrete semiconductor device designed for surface mount applications. Featuring a 30 V peak reverse voltage and 2 A maximum continuous forward current, this Schottky barrier rectifier excels in efficiency and low forward voltage drop, making it ideal for power sensitive circuits.
The diode is encapsulated within a compact 2-pin SOD-128 plastic package, facilitating easy automated placement on PCBs, while its integrated guard ring provides enhanced stress protection. Clip-bond technology enables a high power handling capability and ensures reliability under surge conditions up to 50 A peak.
Operating across a wide temperature range from -55°C to 150°C, the device is suitable for automotive and industrial applications, uniquely supported by the AEC-Q101 qualification. It offers low power consumption and reverse polarity protection, benefitting applications like DC-DC converters, switch mode power supplies (SMPS), and other low voltage rectification circuits.
With a low maximum forward voltage of 420 mV and a peak reverse current rating of 1.5 mA, this single diode configuration device is optimized for efficiency and longevity, supporting high-reliability electronic designs in sectors such as industrial electronics, telecommunications, and automotive electronics.
Designed for low forward voltage and high efficiency applications. Encapsulated in a small, flat SOD-128 plastic SMD package suitable for automated PCB assembly. Provides an average forward current of up to 2 A and a peak surge current of 50 A.
Rated for operating temperatures from -55°C up to 150°C. Offers reverse polarity protection and low power consumption. Qualified to AEC-Q101 automotive standards for reliable performance in harsh environments. Features clip-bond technology ensuring high power capability and mechanical robustness.
Ideal for DC-DC conversion, switch mode power supplies (SMPS), and low voltage rectification. Single diode configuration with peak reverse current of 1.5 mA and maximum forward voltage of 420 mV.
This Nexperia Schottky diode series is a suitable choice for industrial, automotive, telecommunications, and power supply manufacturers seeking a compact, efficient rectifier with automotive qualification and extended temperature capability. Discover reliable semiconductor components with EnvMart’s broad selection.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak reverse voltage rating of this diode is 30 V.
This model can handle a maximum continuous forward current of 2 A.
The dimensions of the SOD-128 package are 4 mm in length, 2.7 mm in width, and 1.1 mm in height.
It operates within a temperature range of -55°C to 150°C.
The maximum forward voltage drop is 420 mV.
The diode can withstand a peak surge current of 50 A.
Yes, it is qualified to AEC-Q101 automotive standards.
This diode is designed for surface mounting.
The peak reverse current rating is 1.5 mA.
It is ideal for applications such as DC-DC conversion, switch mode power supplies (SMPS), and low voltage rectification.
This model features a single diode configuration.
It features clip-bond technology which ensures high power capability and mechanical robustness.
