Nexperia Surface Mount Schottky Diode 60 V 4.2 A 2-Pin SOD-128 PMEG6030ETPX
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 4mm |
| Model | PMEG6030ETPX |
| Width | 2.7mm |
| Mount Type | Surface |
| Series | PMEG6030ETP |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-128 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 4.2A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 150mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 530mV |
| Peak Reverse Recovery Time trr | 12ns |
| Average forward current | IF(AV) ≤ 3 A |
| Reverse voltage | VR ≤ 60 V |
Key Features
- Designed for high efficiency and low forward voltage drop applications.
- Features AEC-Q101 automotive qualification for reliable performance at high temperatures.
- Maximum operating temperature up to 175°C ensures durability in demanding environments.
- Provides low reverse current and fast recovery time for efficient switching.
- Compact surface mount design saves PCB space in electronic circuits.
- Supports peak non-repetitive forward surge current up to 50 A.
- Ideal for battery life extension and general high-performance rectification.
Product Description
Nexperia PMEG6030ETPX is a high-performance Schottky diode designed for surface mount applications requiring 60 V voltage rating and 4.2 A current capacity. Packaged in a small and flat SOD-128 plastic package with 2 pins, this diode utilizes planar MEGA technology with integrated guard ring for stress protection, ensuring robust operation under high temperature and surge conditions.
This Schottky diode features a maximum forward voltage of 530 mV, exceptionally low reverse current, and fast recovery time of 12 nanoseconds, making it suitable for efficient power rectification and protection circuits in automotive, industrial, and consumer electronic applications.
Qualifying to the AEC-Q101 automotive standard, it supports operating temperatures up to 175°C, enabling usage in demanding environments such as advanced electronics, power supplies, and battery management systems. Its compact dimensions of 4 mm length, 2.7 mm width, and 1.1 mm height provide a space-saving solution on densely packed printed circuit boards.
The diode’s robust construction with clip-bonding technology delivers high power capability and reliability, making it an ideal component for extending battery life and enhancing energy efficiency in various multi-market applications.
High-efficiency low forward voltage Schottky rectifier. Surface mount SOD-128 package with 2 pins. AEC-Q101 qualified for automotive industry standards. Maximum continuous forward current: 4.2 A. Peak reverse voltage: 60 V.
Fast reverse recovery time of 12 ns. Operating temperature range from -55°C to 175°C.
This diode is a dependable choice for semiconductor, electronic, automotive, and power supply manufacturers. Explore the wide range of Nexperia semiconductor components on EnvMart for your precision and high-performance requirements.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this Schottky diode is 4.2 A.
The peak reverse voltage rating for this model is 60 V.
The dimensions of the SOD-128 package are 4 mm in length, 2.7 mm in width, and 1.1 mm in height.
This diode operates within a temperature range of -55°C to 175°C.
This model complies with the AEC-Q101 automotive standard.
The maximum forward voltage drop of this diode is 530 mV.
The diode supports a peak non-repetitive forward surge current of up to 50 A.
The reverse recovery time for this Schottky diode is 12 nanoseconds.
This diode uses a surface mount type for installation.
The peak reverse current for this diode is 150 mA.
The diode configuration of this component is single.
This Schottky diode is suitable for automotive, industrial, and consumer electronic applications.
