Crydom 1 Series Solid State Relay, 25 A Load Current, Panel Mount, 140 V AC Load, 32 V DC Control D1225K

Crydom D1225K 1 Series Solid State Relay is designed for reliable and efficient switching of AC loads up to 25 A. It features panel mount construction with a maximum load voltage of 140 V AC and DC control voltage of 32 V, providing versatility in industrial and automation applications.

This relay incorporates zero-cross switching for resistive loads and SCR output suitable for heavy industrial applications requiring high durability. The unit includes internal snubber circuitry for enhanced protection against voltage spikes.

Its compact design with dimensions of 26.4 mm in height and 44.5 mm in length makes it suitable for tight panel spaces. The terminal type is screw, ensuring secure and stable electrical connections.

The relay operates reliably between -40 °C and 80 °C, and features low off-state leakage current of 1 mArms and a capacitance of 8 pF, supporting high-performance switching with minimal signal interference.

Crydom solid state relays meet stringent standards including CE, CSA, RoHS, UL, and VDE certifications, reflecting their quality and suitability for industrial installations. Supports zero cross switching function for efficient AC load control.

Maximum operating temperature is 80 °C with minimum operating temperature of -40 °C. Equipped with screw terminal type for secure connections. Features SCR output type ideal for heavy industrial loads. Compact dimensions with height 26.4 mm and length 44.5 mm.

Internal snubber circuitry enhances reliability and performance. Capacitance of 8 pF and off state leakage current of 1 mArms. Complies with CE, CSA, RoHS, UL, and VDE standards ensuring quality and safety. Filter, cover, and thermal pads are available as accessories (heat sink not included).

Ideal for electrical, industrial automation, and control applications.

This solid state relay is suitable for industrial, electrical, automation, and panel control applications where reliable AC switching with DC control is required. Its robust construction and compliance with international safety standards make it a dependable component for manufacturing, HVAC, and commercial electrical systems.
