Crydom PCV Series Solid State Relay, Panel Mount, 15 A Load, 280 Vrms Load, 2-10 V dc Control 10PCV2415
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 23mm |
| Length | 45.7mm |
| Model | 10PCV2415 |
| Mount Type | Panel |
| Series | PCV |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -30°C |
| Terminal type | Screw |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 15A |
| Standards/Approvals | CE, CSA LR 81689-73, cULus |
| Minimum Control Voltage | 2V dc |
| Maximum Control Voltage | 10V dc |
| Off State Leakage Current | 10mArms |
Key Features
- Features zero cross switching for efficient control.
- Insulating epoxy resin housing provides electrical shock protection.
- Compact dimensions allow installation on crowded panels.
- Screw terminals ensure secure conductor connections.
- Operates reliably in temperatures from -30°C to 80°C.
- Designed to handle electrical surges up to 2500 V.
- Off state leakage current is minimal at 10 mArms.
- Certified to CE, CSA LR 81689-73, and cULus standards.
Product Description
The Crydom 10PCV2415 Solid State Relay is a high-quality panel mount relay engineered for load currents up to 15 A and capable of handling voltages up to 280 Vrms. It features a control voltage range from 2 V dc to 10 V dc, making it suitable for low-voltage control systems often found in industrial automation and manufacturing environments.
Its zero cross switching function reduces electrical noise, ensuring reliable and smooth switching operations. The relay's insulating epoxy resin housing safeguards against electric shock, enhancing safety during installation and operation.
With compact dimensions of 58.4 mm (height) x 45.7 mm (length) x 23 mm (depth), this relay fits efficiently in crowded panel spaces. Screw terminals firmly secure wiring to prevent disconnection from vibration or movement, making it ideal for demanding industrial settings.
The Crydom SSR operates across a wide temperature range from -30°C to +80°C, suitable for both harsh and controlled environments. It also withstands electrical surges up to 2500 V, protecting equipment against transient voltage spikes.
This solid-state relay is commonly implemented in automated assembly lines, processing plants, HVAC systems, and other industrial and commercial applications requiring precise and durable switching solutions. Its long lifespan is ensured by solid-state technology, which avoids wear associated with mechanical relays.
Zero cross switching for reduced electrical noise. Insulating epoxy resin housing for shock protection. Compact size for tight panel installations. Screw terminal connections ensure reliable wiring. Wide operating temperature range from -30°C to 80°C.
High surge voltage protection up to 2500 V. Minimal off-state leakage current at 10 mArms. Compliance with CE, CSA, and cULus standards. Durable solid-state design for extended lifespan.
This Crydom solid state relay is a reliable choice for electronics, electrical panels, industrial automation, manufacturing, and HVAC applications. Explore the full range of Solid State Relays at EnvMart for your control system needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this solid state relay is 15 A.
This model operates with a control voltage range from 2 V dc to 10 V dc.
The dimensions of this relay are 58.4 mm in height, 45.7 mm in length, and 23 mm in depth.
It operates reliably in temperatures ranging from -30°C to +80°C.
This relay features zero cross switching, which helps to reduce electrical noise during operation.
Wiring is secured using screw terminals, which help prevent disconnection from vibration or movement.
It is certified to CE, CSA LR 81689-73, and cULus standards.
The off-state leakage current is minimal at 10 mArms.
This relay is commonly implemented in automated assembly lines, processing plants, HVAC systems, and other industrial applications.
It can withstand electrical surges up to 2500 V, protecting equipment against transient voltage spikes.
The relay features an insulating epoxy resin housing that provides electrical shock protection.
The country of origin for this solid state relay is India.
