HARWIN M20 Series Straight Surface Pin Header, 16 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded M20-8760842

HARWIN M20-8760842 is a high-quality Straight Surface Pin Header featuring 16 male contacts arranged in 2 rows with a 2.54 mm pitch. The connector is designed for board-to-board and wire-to-board applications, providing reliable electrical connections with a current rating of 3A. The housing is made from durable nylon thermoplastic, capable of withstanding the reflow soldering process used in modern PCB assembly.

The contacts are constructed from brass with gold plating to ensure low contact resistance and protection against corrosion. Operating temperatures range from -40°C to 105°C, allowing deployment in industrial, consumer electronics, communications, and control systems. The mating pin length of 5.8 mm supports secure mating with compatible M20 series PCB sockets and jumpers.

This unshrouded pin header is mounted by surface mount technology and offers a straight orientation for easy integration into PCB layouts. The design includes castellations on the housing to enable cutting to desired sizes carefully without damaging the tails, providing design flexibility for custom applications.

M20 Series connectors are a standard choice in embedded PC motherboards and large electronic assemblies, suitable for applications in communications, drives, industrial monitoring, and personal computing sectors.

Constructed with a nylon housing suitable for high temperature soldering processes. Offers a current rating of 3A for reliable electrical performance. Gold-plated brass contacts ensure excellent conductivity and corrosion resistance.

Supports a temperature range from -40°C to 105°C for various operating environments. Includes a mating pin length of 5.8 mm for secure connections. Designed for surface mount installation with straight orientation. The unshrouded design allows flexible cutting of the connector size as needed.

Ideal for embedded PCs, motherboards, and large electronic systems in consumer and industrial applications. Explore the full range of PCB Headers and Connectors available at EnvMart to find optimum solutions for your electronic component needs.
