HARWIN M20 Series Straight Surface Pin Header 8 Contacts 2.54 mm Pitch 2 Row Unshrouded M20-8760442
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | HARWIN |
| Orientation | Straight |
| Current | 3A |
| Model | M20-8760442 |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | M20 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Mating Pin Length | 5.8mm |
Key Features
- Supports a current rating of 3A for efficient electrical performance.
- Constructed with a nylon housing for high temperature resistance.
- Features gold-plated brass contacts to ensure excellent conductivity and corrosion resistance.
- Designed for surface mount installation with straight orientation and male contacts.
- Operates reliably in temperatures ranging from -40°C to 105°C.
- Mating pin length is 5.8 mm, suitable for versatile connector pairing.
- Offers compatibility with board-to-board and wire-to-board connector systems.
- Unshrouded to allow flexible design modifications and easy inspection.
Product Description
HARWIN M20-8760442 is a high-quality Straight Surface Pin Header connector featuring 8 contacts arranged in 2 rows with a 2.54 mm pitch. It is designed for reliable connections in electronic applications including embedded PCs, motherboards, and large electronic systems.
The connector uses a durable nylon housing capable of withstanding the reflow soldering process, benefitting from high temperature thermoplastic material. The brass contacts plated with gold deliver excellent conductivity and durability.
This M20 series pin header facilitates both board-to-board and wire-to-board connections, providing flexible integration options. The straight orientation and unshrouded design allow for ease of assembly and inspection, while the 5.8 mm mating pin length supports multiple connector designs.
Operating temperature ranges from -40°C to 105°C ensure reliable performance in various industrial, consumer electronics, communications, drives and control systems, industrial monitoring, and personal computing environments.
Supports 3A current carrying capacity. Made with nylon housing for thermal resistance and durability. Brass contacts with gold plating to prevent corrosion. Surface mount type with straight orientation. Unshrouded design for design flexibility.
Mating pin length of 5.8 mm suitable for various connectors. Operating temperature from -40°C to 105°C. Compatible with board-to-board and wire-to-board connector systems. Manufactured in Taiwan, Province Of China.
This connector series is widely applicable in industrial, laboratory, electronics manufacturing, communications infrastructure, and other commercial electrical systems. The M20 series offers multiple configuration options and pin mating lengths, making it adaptable for a range of design requirements.
Explore EnvMart for a broad range of electronic connectors and components to enhance your project designs and manufacturing needs.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a maximum current rating of 3A, ensuring efficient electrical performance.
The contacts are arranged with a pitch of 2.54 mm, which is standard for many electronic applications.
It features a nylon housing for thermal resistance and brass contacts that are gold-plated to enhance conductivity and prevent corrosion.
It operates reliably within a temperature range of -40°C to 105°C, suitable for various environments.
This model has 8 contacts arranged in 2 rows, allowing for versatile connections.
It is designed for surface mount installation, which facilitates ease of assembly.
The mating pin length is 5.8 mm, suitable for various connector pairings.
Yes, it is compatible with both board-to-board and wire-to-board connector systems, providing flexible integration options.
It features a straight orientation, which is common for many electronic assemblies.
It uses solder termination, which is typical for secure connections in electronic applications.
This model is manufactured in Taiwan, ensuring adherence to quality standards in production.
It is widely applicable in industrial, laboratory, electronics manufacturing, and communications infrastructure systems.
