TE Connectivity PCI & PCIe Series Straight Edge Connector Through Hole 120-Contacts 1.27 mm Pitch 2 Row Solder 1-5145154-2

TE Connectivity 1-5145154-2 PCI & PCIe Series Straight Edge Connector is a specialized electronic component designed for PCI and PCIe card edge applications. Featuring a 1.27 mm pitch, the connector provides 120 contacts arranged in two rows, facilitating reliable high-density signal transmission in compact spaces. This through hole mount connector ensures robust mechanical stability when soldered onto printed circuit boards.

The contact system utilizes phosphor bronze material, known for excellent conductivity and mechanical strength, plated with gold over nickel to resist corrosion and maintain signal integrity. Operating current is rated at 1 ampere with a voltage rating of 203V AC, making it suitable for various electronic equipment needs requiring stable power and signal connectivity.

The housing is made of durable thermoplastic, ensuring electrical insulation and resistance to environmental factors. This connector functions reliably across a temperature range from minus 55 degrees Celsius up to 85 degrees Celsius, accommodating demanding industrial and commercial operating conditions.

Keying features are incorporated to prevent incorrect mating, while the female contact gender allows it to interface securely with complementary components. Straight orientation complements the mechanical and layout requirements of PCI and PCIe form factor cards, enhancing assembly efficiency and performance.

Constructed with phosphor bronze contacts plated with gold over nickel for corrosion resistance. Rated for 1A current and 203V AC voltage operation. Thermoplastic housing material ensures durability and insulation. Designed to operate between -55°C minimum and 85°C maximum temperatures.

Includes keying way for correct mating and female contact gender. Straight orientation optimized for PCI and PCIe card edge applications. Termination type is solder, supporting secure PCB connections. Compliant with PCI & PCIe series standards, without additional certifications.

This connector is ideal for use in electronics manufacturing, industrial computing, telecommunications, and electronic test and measurement applications. Its reliable construction and precise design ensure dependable performance in demanding environments. It is part of a broad range of TE Connectivity connectors tailored for high-quality fabrication and long service life.
