TE Connectivity AMPMODU MOD II Series Straight Through Hole PCB Header, 3 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 8-102202-4
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 750V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | AMPMODU MOD II |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.3mm |
| Mating Pin Length | 6.1mm |
Key Features
- Constructed with a thermoplastic housing meeting 94V-0 flame retardant standards.
- Designed for Through Hole mounting with shrouded protection for secure connections.
- Copper alloy contacts plated with gold for enhanced conductivity and corrosion resistance.
- Supports a continuous current rating of 3A and voltage rating up to 750V.
- Suitable operating temperature range from -65°C to 105°C for industrial applications.
- Male contact gender with 3.3 mm tail pin length and 6.1 mm mating pin length.
- Standard 2.54 mm pitch spacing ensures compatibility with standard PCB footprints.
- Ideal for wire-to-board connector system implementations in electronics and control systems.
Product Description
TE Connectivity 8-102202-4 AMPMODU MOD II Series Straight Through Hole PCB Header is engineered for dependable signal connections in electronic assemblies and industrial automation systems. This single-row header features 3 contacts spaced at 2.54 mm pitch with a robust thermoplastic housing that adheres to 94V-0 flame retardant standards, ensuring safety and durability.
The header employs copper alloy contacts with gold plating to provide excellent electrical conductivity and long-term corrosion resistance. Its Through Hole mount type facilitates secure soldered connections to PCB pads, while the shrouded design protects contacts from damage and incorrect insertion during assembly.
Rated for 3A current and withstands voltages up to 750V, this connector performs reliably across a wide ambient temperature range from -65°C to 105°C. The male contacts feature precise tail pin and mating pin dimensions (3.3 mm and 6.1 mm respectively) to ensure consistent mechanical and electrical engagement.
TE Connectivity's AMPMODU MOD II interconnect system is a widely adopted industry standard known for compact and economical wire-to-board solutions, ideal for automation, control, instrumentation, and manufacturing equipment.
Thermoplastic housing with 94V-0 flame retardant rating. 3 gold-plated copper alloy contacts provide reliable conductivity. Through Hole mount and shrouded design for robust connections. Supports operation in temperatures from -65°C to 105°C.
Rated 3A current at 750V voltage rating for versatile applications. Single row, 2.54 mm pitch ensures wide compatibility. Male contact gender with defined pin lengths for consistent mating.
This connector is extensively used in electronic device manufacturing, automation control panels, test and measurement equipment, telecommunications, and other industrial applications requiring rugged and dependable PCB connections.
Explore EnvMart's extensive range of TE Connectivity connectors and enhance your electronic assemblies with high-quality interconnect solutions.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a continuous current rating of 3A and a voltage rating of up to 750V.
The contacts are spaced at a standard pitch of 2.54 mm.
It features a thermoplastic housing and copper alloy contacts that are plated with gold for enhanced conductivity and corrosion resistance.
The operating temperature range is from -65°C to 105°C, making it suitable for various industrial applications.
This connector has 3 contacts arranged in a single row.
It is designed for Through Hole mounting, which facilitates secure soldered connections to PCB pads.
The contacts are male, providing a defined connection with compatible female connectors.
The tail pin length is 3.3 mm, ensuring proper engagement with the PCB.
The mating pin length is 6.1 mm, designed for consistent mechanical and electrical engagement.
The thermoplastic housing meets 94V-0 flame retardant standards, ensuring safety in applications.
This connector is part of the AMPMODU MOD II series, designed for wire-to-board applications.
The country of origin for this product is India.
