TDK Standard Metal Oxide Varistor 315 pF 50 A Clamping Voltage 2970 V Varistor Voltage 620 V B72214S0381K101
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 10mm |
| Brand | TDK |
| Material | Metal |
| THICKNESS | 5.9mm |
| Length | 15.5mm |
| Model | B72214S0381K101 |
| Depth | 19mm |
| Mount Type | Lead |
| Series | Standard |
| Energy Rating | 1J |
| Maximum Operating Temperature | 105°C |
| Capacitance | 315pF |
| Minimum Operating Temperature | -40°C |
| Maximum dc Voltage | 1465V dc |
| Standards/Approvals | IEC, VDE, UL, CQC, CSA |
| Lead Pitch | 2.7mm |
| Maximum AC Voltage | 1100V ac |
| Clamping Voltage VC | 2970V |
| Clamping Current | 50A |
| Maximum Surge Current | 4.5kA |
| Varistor Voltage | 620 V |
Key Features
- Varistor voltage rating of 620 V ensures robust voltage protection.
- Clamping voltage of 2970 V provides effective surge suppression.
- Lead mount type with flame-retardant material coating for safety.
- Operates reliably from -40°C up to 105°C temperature range.
- Compact dimensions with 10 mm diameter and 15.5 mm length for versatile applications.
- Maximum surge current capacity of 4.5 kA for high energy transients.
- Complies with IEC, VDE, UL, CQC, and CSA standards for quality assurance.
- Energy rating of 1 J suitable for standard industrial surge protection.
Product Description
TDK B72214S0381K101 Standard Metal Oxide Varistor is designed for surge protection in electronic components and power systems. Featuring a capacitance of 315 pF and a high clamping current of 50 A, this varistor effectively limits transient voltages and protects sensitive circuits.
With a varistor voltage rating of 620 V and clamping voltage of 2970 V, it provides reliable voltage suppression during transient surges. The component is lead-mounted with a flame-retardant coating, enhancing safety and durability in electrical assemblies.
The varistor is suitable for a wide operating temperature range from -40°C to 105°C, offering stable performance under varying environmental conditions. Its compact form factor includes a 10 mm diameter, 15.5 mm length, and 5.9 mm thickness, enabling integration into diverse industrial and electronic applications.
It can withstand maximum surge currents of 4.5 kA and meets international standards including IEC, VDE, UL, CQC, and CSA, ensuring compliance with safety and quality requirements. Varistor voltage rating of 620 V ensures robust voltage protection.
Clamping voltage of 2970 V provides effective surge suppression. Lead mount type with flame-retardant material coating for safety. Operates reliably from -40°C up to 105°C temperature range. Compact dimensions with 10 mm diameter and 15.5 mm length for versatile applications.
Maximum surge current capacity of 4.5 kA for high energy transients. Complies with IEC, VDE, UL, CQC, and CSA standards for quality assurance. Energy rating of 1 J suitable for standard industrial surge protection.
This varistor is ideal for industrial electronics, power supply protection, surge voltage suppression, manufacturing equipment, and various electrical assemblies requiring reliable transient voltage control.
Explore more high-quality surge protection components and Varistors at EnvMart for your professional electronics and industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The varistor voltage rating of this model is 620 V, ensuring robust voltage protection during transient surges.
This unit can withstand a maximum surge current of 4.5 kA, making it suitable for high energy transients.
The varistor has a diameter of 10 mm, a length of 15.5 mm, and a thickness of 5.9 mm, allowing for versatile applications.
The clamping voltage for this model is 2970 V, providing effective surge suppression.
It operates reliably within a temperature range of -40°C to 105°C, ensuring stable performance under varying conditions.
The energy rating of this model is 1 J, suitable for standard industrial surge protection applications.
This unit complies with IEC, VDE, UL, CQC, and CSA standards, ensuring quality assurance and safety.
It features a lead mount type, which is designed for easy integration into electrical assemblies.
The maximum DC voltage rating for this varistor is 1465 V, providing additional protection for circuits.
This model is constructed from metal and features a flame-retardant material coating for enhanced safety.
The capacitance of this unit is 315 pF, which contributes to its surge protection capabilities.
It is designed for applications in industrial electronics, power supply protection, and surge voltage suppression.
