TDK Metal Oxide Varistor Lead Mount 215 pF 50 A Clamping Voltage 2970 V Model B72214S0551K101

TDK B72214S0551K101 Metal Oxide Varistor is a lead-mounted passive component designed for surge protection in electronic circuits. With a varistor voltage of 910 V and clamping voltage of 2970 V, it effectively clamps voltage spikes to prevent damage. It supports a clamping current of 50 A and a maximum surge current rating of 4.5 kA, ensuring durability and reliability under transient conditions.

The device features a capacitance of 215 pF, suitable for high-frequency applications, and operates efficiently within a temperature range of -40°C to 105°C. Its compact form factor includes a length of 15.5 mm, diameter of 10 mm, thickness of 7.2 mm, and depth of 19 mm, making it ideal for integration into dense circuit boards.

This varistor is constructed with metal oxide material and mounted with leads spaced 7.5 mm apart, facilitating easy and secure PCB soldering. It complies with international standards such as VDE, CQC, CSA, UL, and IEC, ensuring global quality and safety compliance. The energy rating of 1J allows the varistor to absorb surge energy effectively, protecting equipment in industrial, manufacturing, laboratory, and electrical power systems.

Leaded varistor element with metal oxide composition for reliable performance. Varistor voltage rated at 910 V suitable for various electronic circuits. Clamping voltage of 2970 V with a maximum surge current of 4.5 kA. Capacitance value of 215 pF allowing stable operation in high-frequency environments.

Operating temperature range from -40°C to 105°C for versatile industrial usage. Compact dimensions: 15.5 mm length, 10 mm diameter, 7.2 mm thickness, and 19 mm depth. Compliance with VDE, CQC, CSA, UL, and IEC standards for quality assurance.

Lead pitch distance is 7.5 mm facilitating easy PCB mounting. Energy rating of 1J providing effective energy absorption during surges. Suitable for industrial, electronic component manufacturing, and power protection applications.

This product is ideal for use in industrial electronics, power supply protection, manufacturing equipment, laboratory instruments, and HVAC electronic control systems. Explore more TDK surge protection solutions and Varistors at EnvMart for reliable component sourcing.
